22336485 Hose | Genuine Volvo Penta Part

🔧 Product Description

A genuine formed hose in the inlet and exhaust system of the Volvo Penta D6-380D-G. The documented installation includes standard and jackshaft layouts, with routing length controlled by the vessel configuration. The hose must match the exact connection diameters and routing to maintain boost integrity.

🚤 Compatibility

• Engine Family: D
• HP Range: 260-480 HP

Full model list at the end of this description.

⚙️ Key Features

• Genuine Volvo Penta inlet / charge-air hose
• Catalogued for the D6-380D-G
• Documented standard routing reference: approximately 780 mm
• Documented jackshaft installation routing reference: approximately 2850 mm
• Designed for turbocharged intake pressure and oil mist exposure
• Verify physical length and vessel layout before ordering
• L=780mm / Ratio 1.94:1. (Volvo assembly listing)

🔌 Function

Carries intake or compressed charge air through the D6 inlet system while accommodating engine movement and installation offset.

⚠️ Common Signs of Failure

• Hissing, loss of boost or reduced acceleration
• Oil mist around hose ends
• Cracks, softening or delamination
• Hose collapse or bulging
• Chafing caused by incorrect routing

🛠️ Service Notes

• Fit hoses only to clean, sound spigots — take off old rubber, scale and corrosion, and renew the spigot or pipe if it is pitted, because no clamp will seal a rough sealing face
• Push the hose fully home so the clamp sits behind the bead or barb rather than over the end of the spigot, and fit new clamps whenever a hose is renewed
• Let the hose follow its natural bend with no kinks and no tension on either connection, clear of hot surfaces and moving parts, with chafe protection wherever it passes a bracket, edge or bulkhead
• Use the correct grade of hose for the duty, and clamp to the standard the installation demands — twin clamps are normal practice on seawater and fuel connections below the waterline
• Refill, vent and run the engine, then check every joint hot and cold and recheck the clamps after the first running period as the hose beds down

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 22336485 → Supersedes 21141638

OEM / Related Numbers

• 21141898 earlier number superseded by this part
• 21141631 earlier number superseded by this part
• 21141638 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D6-330D-E, D6-370D-E, D6-330D-C, D6-370D-C, D6-330D-D, D6-370D-D, D6-330D-F, D6-370D-F, D6-300D-F, D6-310D-C, D6-310D-D, D6-310D-E, D6-440I-G, D6-480I-G, D6-440I-WJ-G, D6-480I-WJ-G, D6-300D-G, D6-340D-G, D6-380D-G, D6-440D-G, D6-480D-G, D6-400A-G, D6-440A-G, D6-435D-D, D6-435D-E, D6-435D-F, D6-435D-C
• Volvo Penta D4-260D-C, D4-260D-E, D4-260D-D, D4-260D-F, D4-300D-C, D4-300D-D, D4-300D-E, D4-300D-F
