22381496 Relief tool | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta relief and support fixture 22381496, listed at 5.597 kg. Volvo Penta's own special tools catalogue designates it a relief tool and lists 14 products against it: the D8A2-A MP and D8A3-A engines, eight D11 and D13 designations, and the IPS15-A, IPS15-B, IPS20-D and IPS30-D drives, so its listed coverage runs wider than the IPS15 steering-spindle work it is best known for. Its pivot screws locate in the intermediate housing so the bearing area can be supported and unloaded before extractor 22381636, which carries the same 14-product list, is used.

⚙️ Key Features

• Designated a relief tool in Volvo Penta's special tools catalogue
• 5.597 kg
• Listed for the D8A2-A MP and D8A3-A, eight D11 and D13 designations and the IPS15, IPS20-D and IPS30-D drives
• Integrated pivot screws locate in the intermediate housing
• Shares its 14-product list with extractor 22381636 and counterhold 78175209

📋 Kit Contents

• 1 × complete relief-tool fixture assembly - 22381496
• Integrated pivot-screw set - serviced only with tool assembly 22381496
• Tool 22381636 extractor and standard handle 9991801 are required by the workshop procedure and are serviced separately

🔌 Function

Supports the intermediate housing and removes load from the needle-bearing area, allowing the bearing to be extracted without distorting or damaging the steering-spindle housing.

⚠️ Common Signs of Failure

• Pivot screws bent, damaged or no longer adjusting
• Fixture not sitting squarely on the intermediate housing
• Support surfaces cracked or distorted
• Signs of overloading from incorrect positioning

🛠️ Service Notes

• Extractor 22381636 carries the identical product list and does the pulling, so the two are normally ordered together
• The published product list is wider than IPS15 alone, so check the tool number against the procedure for your engine or drive

🔄 Supersession & Cross Reference

OEM / Related Numbers

• 22381636 related needle-bearing extractor
• 9991801 related standard tool handle

Other-Brand OEM Numbers

• VOE22381496

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
