22396638 Wiring Harness | Genuine Volvo Penta Part
22396638 Wiring Harness | Genuine Volvo Penta Part
Couldn't load pickup availability
Available on request — contact us
As an authorised Volvo Penta dealer we can source parts through channels not shown online, and check supersession and used options for you
Availability checked daily with Volvo Penta
✓ Authorised Volvo Penta Dealer · Genuine Volvo Penta parts · Ships Australia-wide
🔧 Product Description
Genuine Volvo Penta wiring harness from the Cables and Fuses group, weighing 0.048 kg and listed for 50 D series engine applications. At 48 grams this is a short lead rather than a full engine loom, and the 50-application fitment makes it a widely shared item.
🚤 Compatibility
- Engine Family: D
- HP Range: 110-220 HP
Full model list at the end of this description.
⚙️ Key Features
- 0.048 kg
- Listed for 50 D series engine applications
- Cables and Fuses group
- Short lead rather than a full engine loom
🔌 Function
Carries power or signal between two points in the engine's electrical installation, with the connector types, keying and lead length that installation was designed around.
⚠️ Common Signs of Failure
- An intermittent fault that changes when the lead is moved or flexed
- Green or white corrosion in a connector, or a terminal that has lost its grip
- Insulation chafed through where the lead crosses a hard edge
- A fuse blowing repeatedly on the circuit the lead feeds
- Voltage dropping across the lead under load
🛠️ Service Notes
- Back-probe the connectors under load before condemning the component at either end
- Reinstate the original clips and routing - a lead left loose chafes through in the same place
🔄 Supersession & Cross Reference
Aftermarket / Verified Equivalents
- Related feed pump: 21120406
- Related relay: 872242
- Related clamp: 20799142
📦 Condition
- Genuine Volvo Penta part
- Brand new
- Supplied in original or equivalent packaging
🔎 Full Model Compatibility
Typically suits:
- Volvo Penta D3-220I-G, D3-140A-D, D3-170A-D, D3-200A-D, D3-220A-D, D3-140I-D, D3-140A-E, D3-170A-E, D3-200A-E, D3-220A-E, D3-140I-E, D3-140A-F, D3-170A-F, D3-200A-F, D3-220A-F, D3-140I-F, D3-140A-G, D3-170A-G, D3-200A-G, D3-220A-G, D3-140I-G, D3-110I-D, D3-150I-D, D3-170I-D, D3-200I-D, D3-220I-D, D3-110I-E, D3-150I-E, D3-170I-E, D3-200I-E, D3-220I-E, D3-110I-F, D3-150I-F, D3-170I-F, D3-200I-F, D3-220I-F, D3-110I-G, D3-150I-G, D3-170I-G, D3-200I-G, D3-110I-H, D3-140A-H, D3-170A-H, D3-200A-H, D3-220A-H, D3-150I-H, D3-170I-H, D3-200I-H, D3-220I-H, D3-140I-H
