22461764 Wiring Harness | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta engine loom for TWD series engines, weighing 3.220 kg and listed for two TWD applications. It replaces part number 22061979. This is a full engine harness with its branches and connectors made up, so it is a strip-and-refit job rather than a quick lead change.

🚤 Compatibility

Typically suits:

• Volvo Penta TWD1652GE
• Volvo Penta TWD1653GE

• Engine Family: TWD

⚙️ Key Features

• Replaces 22061979
• 3.220 kg
• Listed for two TWD series applications
• Full multi-branch engine loom

🔌 Function

Runs power, earth and signal around the engine as a single loom, feeding the control unit, sensors and actuators through branches cut to the engine's own layout.

⚠️ Common Signs of Failure

• Faults appearing on several unrelated circuits at once
• Warnings that come and go with engine temperature or vibration
• Sheath chafed through, oil-soaked or heat-hardened
• Connector pins corroded or pushed back in their housings
• Conductor fractured inside a bend, found only under a flexed continuity test

🛠️ Service Notes

• Prove the fault to a branch with a meter before ordering a harness this size - one damaged branch is far more common than a failed loom
• Label the connectors and record the routing before removal, and support the branches so their weight is not hanging on the plugs

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 22461764 → Supersedes 22061979

OEM / Related Numbers

• 22061979 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
