22475160 Wiring Harness | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta transmission cable for the reverse gear on D9 and D16 inboard installations with MG or ZF type transmissions, 4.3 m long and weighing 2.089 kg, listed for 25 D and TAD applications. The 4.3 m length is critical: a 6.3 m version exists for the same installation.

🚤 Compatibility

• Engine Family: D, TAD

Full model list at the end of this description.

⚙️ Key Features

• 4.3 m long
• Reverse gear transmission cable
• For D9 and D16 inboard installations
• MG or ZF type transmissions
• 2.089 kg
• 25 D and TAD applications
• L=4300mm (Volvo assembly listing)

🔌 Function

Carries the electrical connection between the engine's control system and the reverse gear, so shift commands and the gearbox's own signals pass along one made-up loom.

⚠️ Common Signs of Failure

• Gear engagement intermittent, delayed or absent
• Fault codes logged against the transmission circuit
• Outer sheath chafed, cracked or melted where it has touched something hot
• Connector pins corroded, or water standing in the connector shell
• Faults that come and go as the harness is moved by hand

🛠️ Service Notes

• The 6.3 m version of the same cable is 22475161 - measure the run before ordering, because the length is the only thing separating them
• Clip the harness clear of hot and moving parts and leave a service loop at each end
• Pull the connector body, never the cable, when unplugging

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D13C1-A MP, D13C2-A MP, D13C3-A MP, D13C4-A MP, D13B-E MH, D13B-E MH (FE), D13B-N MH, D13B-N MH (FE), D13C6-A MP, D13C1-A MH, D13C2-A MH, D13C5-A MP
• Volvo Penta D11B3-A MP, D11B4-A MP, D11B2-A MP, D11B1-A MP
• Volvo Penta D16C-A MH, D16C-B MH, D16C-C MH, D16C-D MH
• Volvo Penta D9A2L MH, D9A2M MP
• Volvo Penta TAD1240GE
• Volvo Penta TAD1241GE
• Volvo Penta TAD1242GE
