22500131 Wiring Harness | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta transmission cable for the reverse gear on D9 and D16 inboard installations with MGX type transmissions, 6.3 m long and weighing 1.553 kg, listed for 25 D and TAD applications. The MGX transmission type is the critical distinction - the MG/ZF cable of the same length is a different part. It supersedes 22500130.

🚤 Compatibility

• Engine Family: D, TAD

Full model list at the end of this description.

⚙️ Key Features

• For MGX type transmissions
• 6.3 m long
• 1.553 kg
• 25 applications across D and TAD series engines
• Supersedes 22500130
• L=6300mm (Volvo assembly listing)

🔌 Function

Carries the reverse gear control connection between the helm control and the transmission on D9 and D16 inboard installations.

⚠️ Common Signs of Failure

• Gear engagement slow, erratic or absent at the lever
• Operation that comes and goes when the cable is moved
• Outer sheath chafed, cut or crushed
• Connector pins corroded, green or bent
• Stored faults on the transmission control circuit

🛠️ Service Notes

• Match both the transmission type and the 6.3 m length before ordering, since the same cable is listed in other lengths and for other transmission types
• Route the cable clear of hot and moving parts and avoid tight bends at the connector ends

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 22500131 → Supersedes 22500130

OEM / Related Numbers

• 22500130 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D13C1-A MP, D13C2-A MP, D13C3-A MP, D13C4-A MP, D13B-E MH, D13B-E MH (FE), D13B-N MH, D13B-N MH (FE), D13C6-A MP, D13C1-A MH, D13C2-A MH, D13C5-A MP
• Volvo Penta D11B3-A MP, D11B4-A MP, D11B2-A MP, D11B1-A MP
• Volvo Penta D16C-A MH, D16C-B MH, D16C-C MH, D16C-D MH
• Volvo Penta D9A2L MH, D9A2M MP
• Volvo Penta TAD1240GE
• Volvo Penta TAD1241GE
• Volvo Penta TAD1242GE
