22682858 Level Sensor | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta fuel level sensor with a 630 mm nominal length, measuring 627 mm from the top of the tank interior to the bottom of the sensor, weighing 1.012 kg and listed for 106 D series applications. Only the length separates it from the 472 mm, 527 mm and 676 mm sensors. It is an all-in-one fitting for the fuel tank, integrating the level sensor, the fuel inlet and outlet ports for the main engine, the inlet and outlet ports for a diesel heater, de-aeration and the fuel pickup and return pipe in one package, with an M18 fuel outlet port and an M16 fuel return port, and a bayonet fitting designed for the matching service hatch 22548277 in this run.

🚤 Compatibility

• Engine Family: D
• HP Range: 13-480 HP

Full model list at the end of this description.

⚙️ Key Features

• 630 mm nominal length, 627 mm from the top of the tank interior to the bottom of the sensor
• One of four lengths sharing the same fitment list
• All-in-one tank fitting - level sensor, engine feed and return ports, diesel heater ports, de-aeration and pickup and return pipe
• M18 fuel outlet port, M16 fuel return port
• Bayonet fitting, installed through service hatch 22548277
• 1.012 kg
• 106 D series applications
• L=630mm (Volvo assembly listing)
• M18 thread
• Level sensor, engine fuel inlet and outlet, diesel heater inlet and outlet, de-aeration and fuel pickup / return pipe in one package
• Bayonet fitting for installation through the service hatch
• Fuel outlet port: M18
• Fuel return port: M16
• Length: 627 mm (from top of inside tank to bottom of level sensor)
• Fits: Fuel tank installation; used with service hatch 22548277

🔌 Function

Reports the fuel level in the tank to the gauge or display and carries the tank's engine and heater feed, return, de-aeration and pickup connections in a single fitting.

⚠️ Common Signs of Failure

• Gauge reading full or empty regardless of what is in the tank
• Reading sticking at one point as the level falls
• Needle or display value jumping erratically
• Fuel weeping at the tank flange
• Reading that stops short of empty or full because the sender fouls inside the tank

🛠️ Service Notes

• The service hatch 22548277 carries the matching laser-cut bayonet hole for this sensor
• Renew the flange seal and check the earth connection when refitting
• Length is measured from the top of the inside of the tank to the bottom of the level sensor, so measure the tank depth before ordering
• Designed to be installed together with service hatch 22548277

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D6-330A-F, D6-370A-F, D6-330D-F, D6-370D-F, D6-300A-F, D6-300D-F, D6-300I-F, D6-340I-G, D6-380I-G, D6-440I-G, D6-480I-G, D6-300A-G, D6-340A-G, D6-380A-G, D6-440I-WJ-G, D6-480I-WJ-G, D6-300D-G, D6-340D-G, D6-380D-G, D6-440D-G, D6-480D-G, D6-400A-G, D6-440A-G, D6-300I-G, D6-330I-F, D6-370I-F, D6-435D-F, D6-400A-F, D6-435I-F
• Volvo Penta D4-260A-F, D4-260D-F, D4-260I-F, D4-300A-F, D4-300D-F, D4-180I-F, D4-225I-F, D4-300I-F, D4-225A-F, D4-175I-G, D4-230I-G, D4-270I-G, D4-320I-G, D4-300I-G, D4-150A-G, D4-230A-G, D4-270A-G, D4-320A-G, D4-300A-G, D4-145I-G
• Volvo Penta D13C3-B MH, D13C1-B MH, D13C4-B MH, D13C2-B MP, D13C1-A MP, D13C2-A MP, D13C3-A MP, D13C4-A MP, D13B-N MH, D13B-N MH (FE), D13C4-B MP, D13C5-B MP, D13C6-A MP, D13C1-A MH, D13C5-A MP, D13C7-B MP, D13C8-B MP
• Volvo Penta D3-110I-H, D3-140A-H, D3-170A-H, D3-200A-H, D3-220A-H, D3-150I-H, D3-170I-H, D3-200I-H, D3-220I-H
• Volvo Penta D11C1-A MP, D11C3-A MP, D11C2-A MP, D11C4-A MP, D11B3-A MP, D11B4-A MP, D11B2-A MP, D11B1-A MP
• Volvo Penta D8A2-A MP, D8A5-A MH, D8A6-A MH, D8A5-A MG, D8A6-A MG, D8A4-A MP, D8A1-A MP, D8A3-A MP
• Volvo Penta D16C-D MH, D16C1-E MH, D16C1-F MH, D16C2-E MH, D16C2-F MH
• Volvo Penta D2-40F, D2-55F, D2-50F, D2-75F, D2-60F
• Volvo Penta D1-30F, D1-13F, D1-20F
• Volvo Penta D9A2L MH, D9A2M MP
