22754010 Propeller Kit | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta Type H10 Stainless-Steel Duoprop Propeller Set - Part Number: 22754010

A genuine Volvo Penta matched Type H10 stainless-steel Duoprop set for DPH and DPI sterndrives. The set combines a three-blade front propeller and four-blade rear propeller with galvanically isolated, shock-absorbing hubs. H propellers can replace the same-number Type G set, but G and H propellers must never be mixed.

Kit Contents:

• 1 × Type H10 three-blade front propeller - 23623060

• 1 × Type H10 four-blade rear propeller - 23623070

• Propeller cone, nuts, lock bolt and installation tools are serviced separately

• Related H-series propeller cone kit - 23000185

⚙️ Key Features

• Genuine Volvo Penta Type H10 matched propeller set

• Correct Volvo Penta kit number 22754010

• High-strength stainless-steel construction

• Shock-absorbing rubber hubs with galvanic isolation

• Patented three-blade front and four-blade rear geometry for DPH / DPI

🔄 Supersession & Cross Reference

OEM Supersession Chain:

• 22754010 current Type H10 propeller-set reference

OEM / Related Numbers:

• 22754010

• VOE22754010

• 23623060 front propeller

• 23623070 rear propeller

• 23000185 related H-series propeller-cone kit

• 991609 related cone lock bolt

• 23952642 related front propeller nut

• 23777877 related line cutter

• 23161623 related propeller tool

Aftermarket / Verified Equivalents:

• No aftermarket equivalent

🚤 Compatibility

Commonly used on:

• Volvo Penta DPH and DPI Aquamatic sterndrives

• Upgrade from the same-number Type G Duoprop set where the complete matched pair is replaced

Typically suits:

• Engine models:

• D4-230, D4-270, D4-300 and D4-320 installations with approved DPH / DPI gearing

• D4-260 and D4-300 earlier DPH installations upgraded from the same-number Type G pair

• D6-300, D6-340, D6-380, D6-400, D6-440 and D6-480 installations with approved DPH / DPI gearing

• D6-280, D6-310, D6-330, D6-350, D6-370, D6-400 and D6-435 earlier DPH installations upgraded from the same-number Type G pair

• Vessels whose Volvo Penta propeller calculation specifies H10

• • Drive Type: Volvo Penta DPH and DPI

• • Engine Type: Volvo Penta D4 / D6 common-rail marine diesel

• • Year Range: DPH / DPI generation controlled

• • Serial Range: Propeller size is determined by drive ratio, hull load and rated wide-open-throttle rpm; DPH-D / DPH-D1 from serial 302029042 uses the later cone-lock arrangement

🔌 Function

The H10 front and rear propellers rotate in opposite directions to convert drive torque into thrust, balance steering forces and maintain the approved engine loading.

Common signs of failure:

• Vibration caused by bent blades or an unmatched front and rear pair

• Engine cannot reach rated wide-open-throttle rpm

• Cavitation, ventilation or reduced acceleration

• Hub slip, impact damage or blade-edge erosion

• Type G and Type H propellers or different sizes are mixed on the same drive

📦 Condition

• Genuine Volvo Penta part

• Brand new

• Supplied in original or equivalent packaging
