22799854 Mounting Kit | Genuine Volvo Penta Part

🔧 Product Description

A genuine top / bail-mounting package for the Volvo Penta 7-inch Glass Cockpit multifunction display. It allows the display to be mounted above a console or dashboard rather than flush-mounted.

🚤 Compatibility

• Engine Family: V, D
• HP Range: 110-435 HP
• Year Range: Approximately 2010s onward

Full model list at the end of this description.

⚙️ Key Features

• Genuine 7-inch display bail-mount package
• Adjustable display viewing angle
• Matched to Volvo Penta Glass Cockpit housing dimensions
• Marine corrosion-resistant bracket and fasteners
• Display and network cables are ordered separately
• Engine type: Volvo Penta EVC Glass Cockpit navigation and engine-display system

📋 Kit Contents

• Bail / top mounting bracket - serviced under Volvo Penta kit 22799854
• Display retaining knobs and mounting fasteners - supplied within kit 22799854; individual numbers are not published in the indexed accessory listing

🔌 Function

The kit secures the display above the helm surface while allowing the operator to adjust the viewing angle.

⚠️ Common Signs of Failure

• Display bracket is cracked or corroded
• Retaining knobs no longer hold the selected angle
• Display vibrates or moves underway
• Mounting screws pull loose from the console
• An incorrect bracket prevents the display from seating properly

🛠️ Service Notes

• Use all the parts supplied and fit them as a set; the kit is matched, and mixing new parts with reused fasteners or bushes defeats the purpose of buying it
• Renew self-locking nuts, lock washers, tab washers and thread-locking compound rather than reusing the originals
• Check what the kit mounts to before assembly — clean out the threads and look for corrosion, wear, elongated holes and cracks around the fixing points
• Leave the fixings finger-tight until everything is located and aligned, then tighten in the order and to the figures given in the workshop manual for your engine
• Recheck the fixings for tightness after the first period of running, since new mountings bed in and settle

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta V8-350-CE-R, V8-380-CE-R, V8-300-CE-M, V8-350-CE-M, V8-300-CE-N, V8-350-CE-N, V8-380-CE-M, V8-300-CE-R, V8-430-CE-R, V8-430-CE-M, V8-300-CE-P, V8-350-CE-P, V8-380-CE-P, V8-380-CE-N, V8-430-CE-N, V8-430-CE-P, V8-300-CE-S, V8-350-CE-S, V8-400-CE-R
• Volvo Penta D13C1-A MP, D13C2-A MP, D13C3-A MP, D13C4-A MP, D13B-E MH, D13B-E MH (FE), D13B-N MH, D13B-N MH (FE), D13C6-A MP, D13C1-A MH, D13C2-A MH, D13C5-A MP
• Volvo Penta D6-330A-F, D6-370A-F, D6-330D-F, D6-370D-F, D6-300A-F, D6-300D-F, D6-300I-F, D6-330I-F, D6-370I-F, D6-435D-F, D6-400A-F, D6-435I-F
• Volvo Penta V6-200-CE-N, V6-240-CE-M, V6-280-CE-M, V6-240-CE-N, V6-200-CE-P, V6-250-CE-P, V6-280-CE-P, V6-280-CE-N, V6-250-CE-O, V6-250-CE-R, V6-280-CE-R
• Volvo Penta D3-110I-H, D3-140A-H, D3-170A-H, D3-200A-H, D3-220A-H, D3-150I-H, D3-170I-H, D3-200I-H, D3-220I-H, D3-140I-H
• Volvo Penta D4-260A-F, D4-260D-F, D4-260I-F, D4-300A-F, D4-300D-F, D4-180I-F, D4-225I-F, D4-300I-F, D4-225A-F
• Volvo Penta D11B3-A MP, D11B4-A MP, D11B2-A MP, D11B1-A MP
• Volvo Penta D8A1-A MP, D8A2-A MP, D8A3-A MP, D8A4-A MP
• Volvo Penta D9A2L MH, D9A2M MP
• Volvo Penta D16C-D MH
