22838382 Shim | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta shim 0.25 mm thick, listed for seven applications across D series engines and IPS pod drives. It is the thickest of the three shims offered for these applications. It supersedes part number 3861054.

🚤 Compatibility

Typically suits:

• Volvo Penta D6-300D-G
• Volvo Penta D6-340D-G
• Volvo Penta D6-380D-G
• Volvo Penta D6-440D-G
• Volvo Penta D6-480D-G
• Volvo Penta IPS10-A
• Volvo Penta IPS10-B

• Engine Family: D, IPS
• HP Range: 300-480 HP

⚙️ Key Features

• Shim, 0.25 mm thick
• Supersedes part number 3861054
• Listed for seven applications across D series engines and IPS pod drives
• The thickest of the three offered, above the 0.08 mm 22838380 and the 0.13 mm 22838381
• TH=0.25mm (Volvo assembly listing)

🔌 Function

Fills a measured part of the gap in an assembly so the clearance or preload between the components can be brought to specification.

⚠️ Common Signs of Failure

• Knocking or whining from the assembly as the setting drifts
• End float or backlash found out of tolerance at service
• Faces bruised, indented or picked up where the shim has moved
• Shim distorted or cracked so the stack height is no longer true
• Fretting marks and fine debris on the mating faces at strip-down

🛠️ Service Notes

• Calculate the required thickness from measurement and build the stack accordingly
• The three thicknesses fit the same applications, so ordering by thickness is the only reliable route
• The published weights do not increase with thickness across this set, so weight cannot be used to tell them apart

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 22838382 → Supersedes 3861054

OEM / Related Numbers

• 3861054 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
