22846234 Transom Shield | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta transom shield from the Marine Propulsion group, weighing 49.90 kg and listed for 11 applications across D series engines and TSK units. It forms the sealed structural interface between hull and drive, so its condition is both structural and watertight.

🚤 Compatibility

Typically suits:

• Volvo Penta D6-300A-G
• Volvo Penta D6-340A-G
• Volvo Penta D6-380A-G
• Volvo Penta TSK DPI-A
• Volvo Penta D6-400A-G
• Volvo Penta D6-440A-G
• Volvo Penta D4-150A-G
• Volvo Penta D4-230A-G
• Volvo Penta D4-270A-G
• Volvo Penta D4-320A-G
• Volvo Penta D4-300A-G

• Engine Family: D, TSK
• HP Range: 150-440 HP

⚙️ Key Features

• Transom shield from the Marine Propulsion group
• 49.90 kg
• Listed for 11 applications across D series engines and TSK units
• Both a structural member and a watertight seal

🔌 Function

Forms the structural and watertight interface between the hull and the drive, carrying the drive's thrust and steering loads into the transom while sealing the opening it passes through.

⚠️ Common Signs of Failure

• Water in the bilge that appears only under way or when the boat is loaded
• Corrosion streaking or blistering around the transom opening
• Rust or salt weeping from the joint between shield and transom
• Movement or a creak at the transom when the drive is trimmed or steered
• Corroded fasteners and a broken-down sealant bead found on removal

🛠️ Service Notes

• Check the transom itself for softness or water ingress before refitting - a shield is only as sound as the transom behind it
• Renew all the sealing and the fasteners on reassembly; this joint is what keeps the sea out and is not a place to reuse hardware
• A 50 kg assembly needing proper support during removal and fitting

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
