22856074 Delivery Pipe | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta delivery pipe for cylinders 1 and 2, weighing 0.048 kg and listed for 11 D series engine applications. The cylinder positions are the defining detail, since each pipe is formed for its own run.

🚤 Compatibility

Typically suits:

• Volvo Penta D4-175I-G
• Volvo Penta D4-230I-G
• Volvo Penta D4-270I-G
• Volvo Penta D4-320I-G
• Volvo Penta D4-300I-G
• Volvo Penta D4-150A-G
• Volvo Penta D4-230A-G
• Volvo Penta D4-270A-G
• Volvo Penta D4-320A-G
• Volvo Penta D4-300A-G
• Volvo Penta D4-145I-G

• Engine Family: D
• HP Range: 145-320 HP

⚙️ Key Features

• Delivery pipe for cylinders 1 and 2
• 0.048 kg
• Listed for 11 D series engine applications
• Formed for its own run, so the cylinder positions are the defining detail

🔌 Function

Carries fuel at injection pressure from the pump to the injectors for cylinders 1 and 2, its formed shape holding the exact run those two positions need.

⚠️ Common Signs of Failure

• Smell of diesel and a wet trace around the pipe unions
• Rough running, a misfire on those cylinders, or hard starting
• Ticking or hissing at a union where fuel is escaping under pressure
• Union faces found scored, or the pipe end distorted from previous over-tightening
• Cracking at a bend or a clamp point, most often after the pipe has been sprung into place

🛠️ Service Notes

• High pressure fuel pipes are not to be bent, straightened or reused once disturbed - a repaired pipe is a leak and a fire risk waiting to happen
• Fit the pipe free of strain, with its clamps in place, and tighten the unions to the manual's figures; a pipe pulled into position cracks at the bend
• Bleed the system and check for leaks with the engine running afterwards, keeping clear of the pipe while it is under pressure

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
