23057409 Actuator Sleeve | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta actuator sleeve from the Marine Propulsion group, weighing 0.397 kg and listed for six D series applications. It supersedes 3594258, catalogued earlier as a gear selector control and shift mechanism part, so it sits in the shift linkage.

🚤 Compatibility

Typically suits:

• Volvo Penta D2-75F
• Volvo Penta D2-60F
• Volvo Penta 150S-D
• Volvo Penta 150SR-D
• Volvo Penta 150S-C
• Volvo Penta 150SR-C

• Engine Family: D
• HP Range: 60-75 HP

⚙️ Key Features

• Actuator sleeve from the Marine Propulsion group
• 0.397 kg
• Listed for six D series applications
• Supersedes 3594258, catalogued earlier as a gear selector control and as a shift mechanism part

🔌 Function

Converts the shift actuator's movement into the axial travel that engages and releases the gear, sliding along its guide as the selector operates.

⚠️ Common Signs of Failure

• Gear engagement slow, harsh or refusing to select on one side
• Clunk from the drive when shifting, or a gear that jumps out under load
• Movement stiff or notchy when operated by hand on the bench
• Sleeve found scored, stepped or worn oval where it slides
• Grease dried out, or salt water contamination in the mechanism

🛠️ Service Notes

• Check the shift cable adjustment and the actuator's travel before condemning the sleeve - most poor shifting is set-up rather than a worn sleeve
• Renew the seals and re-grease the sliding surface, and inspect the mating bore for matching wear

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 23057409 → Supersedes 3594258 → Supersedes 3586517

OEM / Related Numbers

• 3594258 earlier number superseded by this part
• 3586517 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
