23656548 Wiring Harness | Genuine Volvo Penta Part
23656548 Wiring Harness | Genuine Volvo Penta Part
Couldn't load pickup availability
Available on request — contact us
As an authorised Volvo Penta dealer we can source parts through channels not shown online, and check supersession and used options for you
Availability checked daily with Volvo Penta
✓ Authorised Volvo Penta Dealer · Genuine Volvo Penta parts · Ships Australia-wide
🔧 Product Description
Genuine Volvo Penta jackshaft wiring harness weighing 3.540 kg, listed for six applications across D series engines and IPS pod drives. The jackshaft installation is the selection detail. It supersedes 23085983.
🚤 Compatibility
Typically suits:
- Volvo Penta D6-300D-G
- Volvo Penta D6-340D-G
- Volvo Penta D6-380D-G
- Volvo Penta D6-440D-G
- Volvo Penta D6-480D-G
- Volvo Penta IPS10-B
- Engine Family: D, IPS
- HP Range: 300-480 HP
⚙️ Key Features
- Jackshaft version
- 3.540 kg
- Supersedes 23085983
- Listed for six applications across D series engines and IPS pod drives
- Standard version is the separate harness 23656547
🔌 Function
Carries power and signals between the engine, drive and control system as one made-up loom, routed for the jackshaft installation.
⚠️ Common Signs of Failure
- Intermittent faults or warnings that come and go with vibration
- Connector pins green, corroded or pushed back in the housing
- Insulation chafed through where the loom passes a bracket or edge
- Sheath cracked or hardened near a hot component
- Fault codes for open or short circuits on several unrelated channels
🛠️ Service Notes
- The jackshaft installation is the selection detail - the standard harness 23656547 covers the same six applications and is not interchangeable
- Photograph the routing and clip positions before removal
- Check and clean the mating connectors on the units before fitting
🔄 Supersession & Cross Reference
OEM Supersession Chain
- 23656548 → Supersedes 23085983 → Supersedes 23085977
OEM / Related Numbers
- 23085983 earlier number superseded by this part
- 23085977 earlier number superseded by this part
📦 Condition
- Genuine Volvo Penta part
- Brand new
- Supplied in original or equivalent packaging
