  • 23746426 Wiring Harness | Genuine Volvo Penta Part - photo 2 of 2
1 2

23746426 Wiring Harness | Genuine Volvo Penta Part

23746426 Wiring Harness | Genuine Volvo Penta Part

$458.38 AUD
$458.38 AUD
Sale Sold out
Shipping calculated at checkout.

Available on request — contact us

As an authorised Volvo Penta dealer we can source parts through channels not shown online, and check supersession and used options for you

Availability checked daily with Volvo Penta

✓ Authorised Volvo Penta Dealer · Genuine Volvo Penta parts · Ships Australia-wide

🔧 Product Description

Genuine Volvo Penta wiring harness listed for 40 applications across the TAD, TWD and TADH engine series, weighing 0.229 kg. It supersedes part number 23074672.

🚤 Compatibility

  • Engine Family: TAD, TWD, TADH

Full model list at the end of this description.

⚙️ Key Features

  • 40 applications across TAD, TWD and TADH series engines
  • 0.229 kg
  • Supersedes 23074672

🔌 Function

Carries the electrical connections between engine-mounted components, keeping the individual leads bundled and routed clear of heat and movement.

⚠️ Common Signs of Failure

  • Intermittent faults that come and go with engine vibration
  • Warning lamps or fault codes that cannot be traced to a component
  • Green corrosion inside a connector body
  • Insulation chafed or heat-hardened where the loom passes the manifold
  • A broken conductor inside intact insulation, found on continuity testing

🛠️ Service Notes

  • Photograph the routing and clip positions before removing the old harness
  • Check the connectors at each end before condemning the harness - most faults are at the plugs

🔄 Supersession & Cross Reference

OEM Supersession Chain

  • 23746426 → Supersedes 23074672 → Supersedes 22071229

OEM / Related Numbers

  • 23074672 earlier number superseded by this part
  • 22071229 earlier number superseded by this part

📦 Condition

  • Genuine Volvo Penta part
  • Brand new
  • Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

  • Volvo Penta TAD540-42VE, TAD540-42VE-C
  • Volvo Penta TAD550-51VE, TAD550-52VE-C
  • Volvo Penta TAD570-72VE, TAD570-71VE-B
  • Volvo Penta TAD840-43VE, TAD840-43VE-C
  • Volvo Penta TAD850-52VE, TAD850-52VE-C
  • Volvo Penta TAD880-82GE, TAD880-84VE
  • Volvo Penta TADH880-82GE, TADH880-84VE
  • Volvo Penta TWD1683GE-B, TWD1683VE
  • Volvo Penta TAD1140-42VE
  • Volvo Penta TAD1150-52VE
  • Volvo Penta TAD1170-72VE
  • Volvo Penta TAD1180-83VE
  • Volvo Penta TAD1341-43GE-B
  • Volvo Penta TAD1344-45GE-B
  • Volvo Penta TAD1346GE
  • Volvo Penta TAD1351-53VE
  • Volvo Penta TAD1371-75VE
  • Volvo Penta TAD1380-82GE
  • Volvo Penta TAD1381-85VE
  • Volvo Penta TAD1384-85VE-IWP
  • Volvo Penta TAD1640-42GE-B
  • Volvo Penta TAD1643VE-B
  • Volvo Penta TAD1650VE-B/51VE
  • Volvo Penta TAD1670-72VE
  • Volvo Penta TAD552VE
  • Volvo Penta TAD580-83VE
  • Volvo Penta TAD853VE
  • Volvo Penta TAD870-73VE
  • Volvo Penta TWD1644-45GE
  • Volvo Penta TWD1672-1673GE
  • Volvo Penta TWD1682-83GE
  • Volvo Penta TWD1744GE
