24294040 Hose | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta hose weighing 0.215 kg. It supersedes part number 21923022 and covers its 28 applications across TAD, TWD and TADH series engines.

⚙️ Key Features

• 0.215 kg
• Supersedes 21923022
• 28 applications across TAD, TWD and TADH series engines

🔌 Function

Conveys fluid between two components in the system.

⚠️ Common Signs of Failure

• Perished outer surface
• Internal swelling
• Weeping at a joint
• Abrasion from adjacent parts

🛠️ Service Notes

• Fit hoses only to clean, sound spigots — take off old rubber, scale and corrosion, and renew the spigot or pipe if it is pitted, because no clamp will seal a rough sealing face
• Push the hose fully home so the clamp sits behind the bead or barb rather than over the end of the spigot, and fit new clamps whenever a hose is renewed
• Let the hose follow its natural bend with no kinks and no tension on either connection, clear of hot surfaces and moving parts, with chafe protection wherever it passes a bracket, edge or bulkhead
• Use the correct grade of hose for the duty, and clamp to the standard the installation demands — twin clamps are normal practice on seawater and fuel connections below the waterline
• Refill, vent and run the engine, then check every joint hot and cold and recheck the clamps after the first running period as the hose beds down

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 24294040 → Supersedes 21923022

OEM / Related Numbers

• 21923022 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
