24320-ZY6-610 Honda Shift Shaft Rod | Genuine Used Part

🔧 Product Description

Genuine Honda BF135 BF150 Extra-Long Shift Rod A - Part Number: 24320-ZY6-610

A genuine used Honda Marine shift rod A for selected BF135 and BF150 extra-long-shaft four-stroke outboard motors.

Honda identifies this component as Rod Comp. A, Shift (XL). Its length is matched to the extra-long midsection and it connects the upper shift-shaft assembly to the lower shift linkage.

⚙️ Key Features

• Genuine used Honda Marine shift rod
• Correct OEM part number 24320-ZY6-610
• Factory description: Rod Comp. A, Shift (XL)
• Extra-long-shaft version
• Designed primarily for BF135 and BF150 engines

🚤 Compatibility

Commonly used on

• Honda BF135 and BF150 extra-long-shaft shift assemblies

Published model and frame examples include

• BF135A4 XCA: BASJ-1000001-1099999
• BF135A6: BARJ-1200001-1299999
• BF135AK0 XCA: BASJ-1300001 and above
• BF135AK2: BARJ-1400001 and above
• BF150A5: BANJ-1100001-1199999
• BF150AK0: BANJ-1300001 and above
• Selected BF150D / DK1 model groups including BBTJ-8000001 and later
• Selected BF115J applications only where the parts diagram specifies 24320-ZY6-610
• HP Range: Primarily 135HP-150HP
• Engine Type: Honda inline four-cylinder EFI four-stroke outboard
• Shaft Configuration: Extra-long / XL

🔌 Function

The rod transfers shift movement through the extra-long midsection to the lower linkage and gearcase.

⚠️ Common Signs of Failure

• Rod is bent
• Threads or pin holes are damaged
• Gearcase does not fully engage
• Shift adjustment cannot be maintained
• Corrosion causes the rod to bind
• Excessive free play develops
• Incorrect shaft-length rod prevents assembly

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 24320-ZY6-610 current extra-long-shaft rod reference
• 24320-ZY6-000 is the related long-shaft version
• Shaft-length variants are not interchangeable

OEM / Related Numbers

• 24320-ZY6-610
• 24320ZY6610
• 24320-ZY6-000 related long shift rod
• 24327-ZW1-000 related stopper ring
• 24610-ZY6-000 related shift shaft A
• 24620-ZY6-000 related shift shaft B
• 24629-ZY6-000ZA related seal holder

Aftermarket / Verified Equivalents

• No aftermarket equivalent

📦 Condition

• Confirm extra-long-shaft fitment before purchase
• Genuine used part
• Removed from running engine where applicable
• In good working condition unless otherwise stated
