3107 Dunbier Loader Beach Retrieve System (2 x 3106 and 2 x 3252) | Marine Trailer Part

🔧 Product Description

Dunbier Loader Beach Retrieval System – Part Number: 3107

A bolt-on rear retrieval system for Dunbier Loader-series boat trailers. The kit clamps to the rear cross member and uses left- and right-hand roller lead-in assemblies to capture and centre the hull in shallow-water, beach and difficult-ramp retrieval conditions.

⚙️ Key Features

• Designed for Dunbier Loader-series trailers
• Clamps to the rear cross member
• Left- and right-hand roller guidance
• Improves hull capture in shallow or uneven retrieval conditions
• No welding required when fitted to the compatible cross member

📏 Specifications

• Kit includes: 2 × Dunbier 3106 left/right roller-system components
• Kit includes: 2 × Dunbier 3252 slide-frame clamps
• Roller rail and keel rollers are not included
• Cross-member dimensions and trailer generation must be verified

🔄 Cross Reference & Related Parts

• Dunbier: 3107
• Lead-in roller system: Dunbier 3106
• Slide-frame mount: Dunbier 3252
• Glider retrofit alternatives: Dunbier 3108 and 3109

🚤 Trailer Compatibility & Application

• Suitable for Dunbier Loader-series trailers with the compatible rear cross member
• Useful for beach launching and ramps where the trailer remains partly out of the water
• Final adjustment must suit the hull width, keel depth and strake position

🔌 Function

Creates a wider rear capture zone that centres the hull before it reaches the main roller bed.

⚠️ Common Signs of Failure

• Roller arms are bent or seized
• Clamps move on the cross member
• Boat contacts the frame rather than the rollers
• Left and right guides sit at different heights
• Rollers are cracked or missing

🛠️ Installation & Safety

• Clamp only to a sound rear cross member
• Position both sides symmetrically
• Keep guides clear of chines and hull fittings
• Tighten clamp hardware evenly
• Test at low retrieval speed and adjust before regular use

📦 Condition

• Brand new Dunbier Marine Products trailer component
• Supplied as one Loader beach retrieval kit with paired roller systems and clamps
• Supplied in original or equivalent packaging
