3583586 Bracket | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta front-mounted universal bracket from the Power Take-Off group, weighing 13.336 kg and listed for the MD2040A to MD2040D, TAMD22, TMD22, MD22, D2-55 A to F, D2-60 and D2-75 A, B, C and F. It is supplied as bracket plus fittings so a cooling compressor, hydraulic pump or similar can be driven from the front of the engine, and it carries much the longest engine list of the five universal brackets listed here. The pulley and drive belt are ordered separately, and an S-drive installation also needs adapter kit 3583805.

⚙️ Key Features

• For MD2040A to D, TAMD22, TMD22, MD22, D2-55 A to F, D2-60 and D2-75 A, B, C and F
• 13.336 kg
• Front mounted, supplied as bracket and fittings
• Pulley and drive belt not included
• Adapter kit 3583805 needed on S-drive installations
• Front mounted, for a cooling compressor, hydraulic pump or similar auxiliary
• Fits: MD2040A, MD2040B, MD2040C, MD2040D, TAMD22, TMD22, MD22, D2-55 A, D2-55 B, D2-55 C, D2-55 D, D2-55 E, D2-55F, D2-60, D2-75 A, D2-75 B, D2-75 C, D2-75F

📋 Kit Contents

• Bracket
• Fittings

🔌 Function

Provides the front-mounted platform that carries a belt-driven auxiliary unit off the engine as a power take-off.

⚠️ Common Signs of Failure

• Belt running off line or shedding dust
• Bracket cracked around the mounting holes
• Accessory shifting under load
• Fixings working loose or elongating their holes
• Corrosion at the joint faces

🛠️ Service Notes

• The pulley and drive belt are not included, so budget for both
• Adapter kit 3583805 is needed with S-drive installations
• A universal bracket gives adjustment, so set and check the belt line across the whole drive after fitting

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
