3583734 Accessories Kit | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta hot water outlet listed for the KAD32, weighing 1.087 kg. It supersedes 3581633, which was catalogued earlier as a set. The connection is made into the engine cooling system so hot coolant can circulate through a water heater and provide a domestic hot water supply; the recommended hose between engine and heater is 952969, the 16 mm bore, and the domestic supply hose is 952968 at 12.7 mm, both with stainless steel clips 961665.

⚙️ Key Features

• Listed for KAD32 engines
• Recommended hoses 952969 and 952968 with clips 961665
• 1.087 kg
• Supersedes 3581633, previously catalogued as a set
• Uses engine coolant heat to supply domestic hot water through a calorifier
• Fits: KAD32

🔌 Function

Takes heated coolant off the engine to feed a calorifier or cabin heater circuit.

⚠️ Common Signs of Failure

• Coolant loss and staining at the outlet joints
• Corrosion or erosion at the outlet spigots
• Cracking at a flange or spigot root
• Hoses swollen or perished where they clamp on
• Airlocks or poor heater output after topping up

🛠️ Service Notes

• The number it replaces was catalogued as a set, so check what was supplied before against what you are ordering now
• The outlets are listed one per engine group - KAD32 is the listing this one sits against
• Renew the hoses and clips at the same time; they are usually the same age as the outlet
• Recommended hose between engine and water heater is 952969, internal diameter 16 mm, with stainless steel hose clips 961665
• Recommended hose for the domestic supply is 952968, internal diameter 12.7 mm, with the same clips 961665

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 3583734 → Supersedes 3581633

OEM / Related Numbers

• 3581633 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
