3809926 Pulley | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta extra pulley with 1 groove on a 165 mm outer diameter, a PK6 multi-V belt groove and a 90 mm length, weighing 2.461 kg and listed for 153 applications on D series engines. An extra pulley lets auxiliary equipment such as a cooling compressor or hydraulic pump be driven from the crankshaft belt. It supersedes 3584504, previously listed simply as a pulley.

🚤 Compatibility

• Engine Family: D
• HP Range: 145-480 HP

Full model list at the end of this description.

⚙️ Key Features

• 1 groove on a 165 mm outer diameter
• PK6 multi-V belt groove, 90 mm length
• 2.461 kg
• 153 applications on D series engines
• Supersedes 3584504
• Grooves per pulley: 1
• Length: 90 mm
• Outer diameter: 165 mm
• V belt groove: PK6
• Fits: Volvo Penta engines fitted with a front mounted universal bracket for auxiliary drive

🔌 Function

Provides the belt groove needed to drive an auxiliary unit from the power take-off with a multi-V belt.

⚠️ Common Signs of Failure

• Squeal from the belt, or belt dust around the pulley
• Ribs in the groove worn, polished or damaged
• Belt tracking off to one side
• Vibration from the drive at certain speeds
• Mounting fastener found slack

🛠️ Service Notes

• Extra pulley 3809925 is the V-belt version with 3 grooves on the same 165 mm outer diameter and an HC50 groove; only 115 grams separate them, so order by belt type and groove profile
• The load an extra drive can take depends on belt alignment, belt type and engine type, so set the alignment carefully after fitting
• Fit a matching new belt and re-check the drive after the first few hours
• Maximum power supplied depends on the alignment of the belt, the belt type and the engine type
• The axial location of the pulley and the position of the driven equipment must suit the power being taken

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 3809926 → Supersedes 3584504

OEM / Related Numbers

• 3584504 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D6-370A-C, D6-350A-A, D6-350A-B, D6-330A-D, D6-330D-E, D6-370D-E, D6-370D-B, D6-330D-B, D6-330A-F, D6-370A-F, D6-370D-A, D6-330D-C, D6-330A-C, D6-370D-C, D6-330D-D, D6-370D-D, D6-330D-F, D6-370A-D, D6-330A-E, D6-370A-E, D6-370D-F, D6-330I-D, D6-310I-B, D6-280I-B, D6-280I-C, D6-280I-D, D6-280I-E, D6-310I-D, D6-435I-D, D6-310I-E, D6-280I-A, D6-310I-A, D6-300A-F, D6-300D-F, D6-300I-F, D6-310D-B, D6-310D-D, D6-310D-C, D6-310D-E, D6-370I-A, D6-370I-B, D6-330I-B, D6-330I-C, D6-370I-C, D6-370I-D, D6-310A-B, D6-280A-C, D6-310A-C, D6-310A-A, D6-280A-D, D6-310A-D, D6-280A-E, D6-310A-E, D6-310I-C, D6-280A-A, D6-280A-B, D6-340I-G, D6-380I-G, D6-440I-G, D6-480I-G, D6-300A-G, D6-340A-G, D6-380A-G, D6-440I-WJ-G, D6-480I-WJ-G, D6-300D-G, D6-340D-G, D6-380D-G, D6-440D-G, D6-480D-G, D6-400A-G, D6-440A-G, D6-300I-G, D6-330I-F, D6-370I-F, D6-400A-E, D6-435D-A, D6-435D-D, D6-435D-E, D6-435D-F, D6-435I-A, D6-435I-C, D6-435I-E, D6-400A-F, D6-435D-C, D6-435I-F, D6-330I-E, D6-370I-E, D6-330A-B, D6-370A-B
• Volvo Penta D4-260A-B, D4-260A-A, D4-260A-C, D4-260A-D, D4-260A-E, D4-260A-F, D4-260D-B, D4-260D-C, D4-260D-D, D4-260D-E, D4-260D-F, D4-260I-A, D4-260I-B, D4-260I-C, D4-260I-D, D4-260I-E, D4-260I-F, D4-300A-A, D4-300A-C, D4-300A-D, D4-300A-E, D4-300A-F, D4-300D-A, D4-300D-C, D4-300D-D, D4-300D-E, D4-300D-F, D4-300I-A, D4-180I-C, D4-225I-C, D4-180I-D, D4-225I-D, D4-180I-E, D4-225I-E, D4-180I-F, D4-225I-F, D4-210A-A, D4-210A-B, D4-225A-B, D4-225A-C, D4-225A-D, D4-300I-C, D4-300I-D, D4-300I-E, D4-300I-F, D4-225A-E, D4-225A-F, D4-210I-A, D4-210I-B, D4-180I-B, D4-225I-B, D4-175I-G, D4-230I-G, D4-270I-G, D4-320I-G, D4-300I-G, D4-150A-G, D4-230A-G, D4-270A-G, D4-320A-G, D4-300A-G, D4-145I-G, D4-175 VG
