3812917 Rudder Indicator | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta rudder position instrument, 52 mm, in white, from the Industrial and Marine Equipment group, weighing 0.100 kg and listed for 294 applications across D, V and VMM series. It supersedes part number 881659, catalogued earlier as a rudder indicator. Conventional steering systems also need sensor kit 3809099, and DPH and DPR drives need mounting kit 3594073 as well; IPS and electronically steered Aquamatic and inboard installations need neither.

🚤 Compatibility

• Engine Family: D, V, VMM
• HP Range: 110-480 HP

Full model list at the end of this description.

⚙️ Key Features

• White face
• 52 mm instrument
• Needs sensor kit 3809099 on conventional steering
• DPH and DPR also need mounting kit 3594073
• 0.100 kg
• Supersedes 881659
• 294 applications across D, V and VMM series
• Gauge diameter: Ø 52 mm
• Gauge family: Rudder and trim gauges
• Gauge range: EVC gauge range
• 52 mm instrument diameter
• Anti-fogging membrane and full backlighting
• Plug-and-play serial connection - adding instruments is easy
• Diameter: 52 mm
• Face colour: White

🔌 Function

Shows the rudder angle at the helm so the operator can see which way the rudder is turned and find centre.

⚠️ Common Signs of Failure

• Needle dead or stuck while the rudder moves
• Angle shown that does not match the rudder
• Centre position wandering off the amidships mark
• Panel illumination out behind a working needle
• Moisture or staining behind the glass

🛠️ Service Notes

• Check what the steering arrangement calls for: sensor kit 3809099 on conventional systems, mounting kit 3594073 in addition on DPH and DPR, and neither on IPS or electronically steered Aquamatic and inboard installations
• Black-faced 3812914 is the same instrument for dark panels
• Recalibrate the feedback sender and confirm the amidships setting after fitting
• Front ring and mounting items are not supplied with the instrument and are ordered separately: 52 mm black 874709 or chrome 874733, 85 mm black 874708 or chrome 874732, 110 mm black 3847888 or chrome 3885216 for panels up to 12 mm (15 mm at 110 mm); 881611/881613 in 52 mm and 881612/881614 in 85 mm for panels 12-25 mm; X-rings 874843 in 52 mm and 874844 in 85 mm for flush mounting
• For a conventional steering system also order sensor kit 3809099; DPH and DPR also require mounting kit 3594073
• Sensor and mounting kits are not needed for IPS, or for Aquamatic and inboard installations with electronic steering
• The other face colour is 3812914

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 3812917 → Supersedes 881659

OEM / Related Numbers

• 881659 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:
