3817171 Cable Kit | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta 4-pole cable for the Boat Trim System, 2.5 m long, from the Marine Propulsion group, weighing 0.236 kg and listed for 27 applications on D4 and D6 engines. It supersedes part number 1140720, catalogued earlier simply as a cable. This is the cable that serves the interceptor units, and the ordering guide takes one per interceptor: two for a pair of 300 mm or 450 mm interceptors, four where four are fitted. Two of these 2.5 m cables are supplied in the 300 mm kit.

🚤 Compatibility

• Engine Family: D
• HP Range: 145-480 HP

Full model list at the end of this description.

⚙️ Key Features

• 4-pole, 2.5 m long
• One cable per interceptor unit
• Supplied in the 300 mm Boat Trim System kit
• 0.236 kg
• Supersedes 1140720, catalogued earlier as a cable
• Supplied in the 300 mm kit 21914554
• Poles: 4
• Length: 2.5 m
• Fits: Volvo Penta Boat Trim System installations

🔌 Function

Carries power and control signals between the Boat Trim System control unit and an interceptor unit.

⚠️ Common Signs of Failure

• Interceptor dead or working only intermittently
• Connector pins green, powdery or loose in their housing
• Insulation chafed, cut or cracked along the run
• Slow or weak blade movement from voltage lost in the cable
• Cable stiff and cracking where it has been flexed

🛠️ Service Notes

• The 4.0 m version of the same cable is 3817172 - measure the run, as length is the only difference between them
• The Boat Trim System uses this 4-pole cable at the interceptors and a separate 6-pole cable elsewhere in the system, so check the pole count as well as the length
• Route the cable clear of chafe points and keep the connections dry
• Two lengths are listed: 3817172 is the 4.0 m version - measure the run before ordering
• The ordering guide takes two cables for a two-interceptor installation and four for a four-interceptor installation

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 3817171 → Supersedes 1140720

OEM / Related Numbers

• 1140720 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D6-340I-G, D6-380I-G, D6-440I-G, D6-480I-G, D6-300A-G, D6-340A-G, D6-380A-G, D6-440I-WJ-G, D6-480I-WJ-G, D6-300D-G, D6-340D-G, D6-380D-G, D6-440D-G, D6-480D-G, D6-400A-G, D6-440A-G, D6-300I-G
• Volvo Penta D4-175I-G, D4-230I-G, D4-270I-G, D4-320I-G, D4-300I-G, D4-230A-G, D4-270A-G, D4-320A-G, D4-300A-G, D4-145I-G
