3857761 Valve | Genuine Volvo Penta Part
3857761 Valve | Genuine Volvo Penta Part
Couldn't load pickup availability
Available — dispatched within 5 business days
Orders dispatch within 5 business days of payment, and we contact you if it will be longer
Availability updated daily
Fits these engines
✓ Authorised Volvo Penta Dealer · Genuine Volvo Penta parts · Ships Australia-wide
🔧 Product Description
Genuine Volvo Penta valve to the late specification, from the Inlet and Exhaust System group, weighing 0.100 kg and listed for 69 applications across the V family.
🚤 Compatibility
- Engine Family: V
- HP Range: 200-225 HP
Full model list at the end of this description.
⚙️ Key Features
- Late specification
- 0.100 kg
- 69 applications across the V family
- Inlet and Exhaust System group
- 2 used per assembly
🔌 Function
Opens and closes the port against its spring, sealing the chamber on the closing stroke and shedding heat through its seat and guide.
⚠️ Common Signs of Failure
- Compression down and a misfire on one cylinder
- Puffing back through the inlet or exhaust as the engine turns
- Rough idle that smooths out as revs rise
- Head or seat face burnt, pitted or receded
- Stem worn or bent, or the tip hammered flat
🛠️ Service Notes
- The late marking matters — the standard size valve in the Engine group is 3857666 at 0.129 kg, and fitting 0.029 kg of difference into the wrong head is not a mistake worth making
- Fitting 3857763 is the other late-specification item here on the same 69 applications, so check whether both are called for
- Inspect the guide and seat before fitting, then recut or lap as the manual requires and reset the clearance
📦 Condition
- Genuine Volvo Penta part
- Brand new
- Supplied in original or equivalent packaging
🔎 Full Model Compatibility
Typically suits:
- Volvo Penta 5.7GSPEFS, 5.7GL-A, 5.7GL-B, 4.3OSi-GF, 4.3OSi-J, 4.3OSi-JF, 5.0GL-A, 5.0GL-B, 5.0GLPEFS, 4.3Gi-200-R, 4.3GIJBYA, 4.3GIPBYCCE, 4.3GIPEFS, 4.3GIPWTRCE, 4.3GiJWTR, 4.3GL-A, 4.3GL-B, 4.3GL-C, 4.3GL-D, 4.3GL-E, 4.3GL-EF, 4.3GL-G, 4.3GL-GF, 4.3GL-J, 4.3GL-JF, 4.3GL-P, 4.3GLPBYC, 4.3GLPEFS, 4.3GLPWTR, 4.3GSPBYC, 4.3GSJBYA, 4.3GSPWTR, 4.3GSJWTR, 4.3GXi-225-R, 4.3GXiE-225-R, 4.3GXi-A, 4.3GXi-B, 4.3GXi-BF, 4.3GXi-C, 4.3GXi-CF, 4.3GXi-D, 4.3GXi-DF, 4.3GXi-E, 4.3GXi-EF, 4.3GXiE-M, 4.3GXi-P, 4.3GXiE-P, 4.3GXi-Q, 4.3GXiE-Q, 4.3GXi-F, 4.3GXi-FF, 4.3GXi-G, 4.3GXi-GF, 4.3GXi-J, 4.3GXi-JF, 4.3OSi-BF, 4.3OSi-B, 4.3OSi-C, 4.3OSi-CF, 4.3OSi-D, 4.3OSi-DF, 4.3OSi-E, 4.3OSi-EF, 4.3OSi-F, 4.3OSi-FF, 4.3OSi-G
- Volvo Penta V6-200-A, V6-225-A, V6-225-E-A
