3862246 Steering Knuckle | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta steering knuckle from the Marine Propulsion group, weighing 0.581 kg and listed for 21 applications across the DPH, D, DPI and DPR series drives. Bushing 3862217, sealing ring 3862245, retainer 3862247 and thrust washer 3862248 all share those same 21 applications and make up the rest of the joint.

🚤 Compatibility

• Engine Family: DPH, D, DPI, DPR
• HP Range: 150-440 HP

Full model list at the end of this description.

⚙️ Key Features

• 0.581 kg
• 21 applications across the DPH, D, DPI and DPR series
• Steering pivot component
• Works with 3862217, 3862245, 3862247 and 3862248

🔌 Function

Forms the pivot that the steering effort acts through, turning the drive to steer the boat.

⚠️ Common Signs of Failure

• Play or knock in the steering when the wheel is rocked
• Steering feeling vague, heavy or wandering at speed
• Pivot bore or pin worn, scored or stepped
• Squeaking or groaning as the drive is steered
• Corrosion and water behind a failed seal at the pivot

🛠️ Service Notes

• Steering is a control system — do not defer work on a knuckle with play or seizure in it, and test the steering through full lock before going afloat
• Renew bushing 3862217, sealing ring 3862245, retainer 3862247 and thrust washer 3862248 while the joint is apart
• Grease the pivot on assembly and torque the fixings to specification

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D6-330A-F, D6-370A-F, D6-300A-F, D6-300A-G, D6-340A-G, D6-380A-G, D6-400A-G, D6-440A-G, D6-400A-F
• Volvo Penta D4-260A-F, D4-300A-F, D4-225A-F, D4-150A-G, D4-230A-G, D4-270A-G, D4-320A-G, D4-300A-G
• Volvo Penta DPH-D1, DPH-E
• Volvo Penta DPI-A
• Volvo Penta DPR-D
