3862683 Pivot Pin | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta pivot pin listed for trim cylinder part number 387960, weighing 0.143 kg and covering 33 applications across the D, TSK, DPH and DPR families. The trim cylinder reference is the point to match, and it separates this pin from pivot pin 3862809 at 0.109 kg.

🚤 Compatibility

• Engine Family: D, TSK, DPH, DPR
• HP Range: 225-400 HP

Full model list at the end of this description.

⚙️ Key Features

• Listed for trim cylinder part number 387960
• Fits the D, TSK, DPH and DPR families
• 33 listed applications
• 0.143 kg, heavier than pivot pin 3862809

🔌 Function

Forms the hinge point the trim cylinder swings on, carrying the load as the cylinder pushes and pulls.

⚠️ Common Signs of Failure

• Knock or clonk from the trim gear as the drive is loaded
• Pin worn stepped, scored or bent
• Trim slop or sideways play at the cylinder end
• Pin seized in its bore by corrosion
• Bush or bore around the pin worn oval

🛠️ Service Notes

• Renew the bushes and any retaining clips with the pin, since a worn bore will wear a new pin quickly
• Grease the pin on assembly, as a dry pin in salt water seizes and then wears fast
• Pivot pin 3862809 is the other pin in this group and is lighter, so match the numbers

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D6-370A-C, D6-330A-D, D6-330A-C, D6-370A-D, D6-330A-E, D6-370A-E, D6-280I-D, D6-310I-D, D6-330I-C, D6-330I-D, D6-280A-C, D6-310A-C, D6-280A-D, D6-310A-D, D6-280A-E, D6-310A-E, D6-280I-C, D6-310I-C, D6-400A-E
• Volvo Penta D4-260A-C, D4-260A-D, D4-260A-E, D4-300A-C, D4-300A-D, D4-300A-E, D4-225I-C, D4-225I-D, D4-225A-C, D4-225A-D, D4-225A-E
• Volvo Penta DPH-A
• Volvo Penta DPR-A
• Volvo Penta TSK DPH-A
