396514 Aftermarket Bombardier Carburetor Float | Sawley's Select Marine Parts

🔧 Product Description

Aftermarket Johnson/Evinrude/OMC carburettor float and arm - Replacement Part Number: 396514

A replacement float-and-arm assembly for selected Johnson, Evinrude, OMC and BRP carburettors from 3HP through 20HP. Part number 396514 supersedes 375919 and is also supplied within selected aftermarket carburettor repair kits. Confirm the carburettor diagram for the engine model and year.

⚙️ Key Features

• Precision replacement carburettor float

• Maintains the specified fuel level in the float bowl

• Operates the needle valve as fuel level rises and falls

• Helps prevent flooding, fuel starvation and unstable mixture

• Direct replacement where the original float number matches

🔄 Supersession & Cross Reference

OEM Supersession Chain:

• 396514 → Supersedes 375919

OEM / Related Numbers:

• 396514

• 0396514

• 375919

• 0375919

Aftermarket / Verified Equivalents:

• Sierra repair kit containing the float: 18-7043

• Aftermarket reference: AM396514

🚤 Compatibility

Commonly used on:

• Johnson, Evinrude, OMC and BRP small carburetted two-stroke outboards

Typically suits:

• Engine models:

• 3HP through 20HP carburettors where OEM 396514 is specified

• Documented applications include selected 5HP, 6HP and 8HP model years

• HP Range: 3HP - 20HP

• Engine Type: Carburetted two-stroke outboard

• Year Range: Determined by the engine model and carburettor diagram

🔌 Function

The float rises and falls with the fuel level in the carburettor bowl and moves the inlet needle to control fuel entry. Correct float height is essential for stable mixture and reliable operation.

Common signs of failure:

• Fuel flooding or overflow from the carburettor

• Rich running, smoke or spark-plug fouling

• Fuel starvation, lean surge or loss of power

• Hard starting or stalling as bowl level changes

• Float absorbs fuel, sticks, cracks or no longer closes the needle correctly

📦 Condition

• Brand new aftermarket replacement part

• New and unused

• Supplied in manufacturer or equivalent protective packaging
