408614 Anchor Roller Device | Marine Anchoring Solutions

🔧 Product Description

Standard Stainless Steel Bow-Roller Nose Section - Part Number: 408614

A standard-height stainless-steel nose section for compatible 408606 and 408609 bow rollers. The forward red roller extends the rode lead and assists the anchor shank in approaching and seating on the main bow roller.

⚙️ Key Features

• Stainless-steel nose-section frame

• Red replaceable forward roller

• Designed for compatible 4-inch and 6-inch bow rollers

• Extends the anchor-support point beyond the mounting base

• Serviceable bolt and pin hardware

📏 Specifications

• Internal width: Approximately 55mm

• Front opening: Approximately 63mm

• Replacement roller: 761105

• Replacement pin kit: 402226

• Attachment bolt kit: 402225

🔄 Cross Reference & Comparable Options

• Compatible bow rollers: 408606 and 408609

• Higher narrow alternative: 408624

🛠️ Installation & Use

• Attach only to the compatible bow-roller frame

• Use the matched 402225 bolt kit and 402226 pin kit where required

• Confirm the anchor shank and shackle clear the 63mm opening

• Check free roller rotation and secure all fasteners

• Do not treat the nose section as a standalone deck fitting

📦 Condition

• Brand new

• Supplied as one standard stainless-steel nose section

• Supplied in original or equivalent packaging
