41103801 Isolation | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta sound absorbent panel, non-adhesive, 500 x 1000 mm and 30 mm thick, weighing 1.700 kg. The panels are made of recycled polyurethane foam at a density of 100 kg per cubic metre, faced with an oil-resistant aluminium foil that can be wiped clean, and treated with a fire-resistant formula that withstands up to 200 degrees C. They are approved for installation in boats CE marked to EU Directive 2013/53/EU. It supersedes part number 61050213, which was catalogued earlier as insulation, and is the middle thickness of the non-adhesive set between the 20 mm 41103800 and the 50 mm 41103802.

⚙️ Key Features

• Non-adhesive, 500 x 1000 mm, 30 mm thick
• Recycled polyurethane foam at 100 kg per cubic metre
• Oil-resistant aluminium foil facing
• Fire-resistant to ISO 3795, withstands up to 200 degrees C
• 1.700 kg
• Supersedes 61050213
• Made of recycled polyurethane foam
• Density of 100 kg/m3 (6.24 lb/ft3)
• Protection film of aluminium foil
• Fire proof registration ISO 3795 (FMVSS 302)
• Temperature resistance: max. 200 degrees C (390 degrees F)
• Oxygen index 24% according to ASTM D2863-91, and fulfils ISO 4589-3
• Approved for installation in boats CE marked according to EU Directive 2013/53/EU
• Covered with an oil resistant foil that is easily cleaned of oil spray
• Density: 100 kg/m3 (6.24 lb/ft3)
• Dimension: 500 x 1000 mm (20 x 40 in)
• Oxygen index: 24% (ASTM D2863-91)
• Rear side: Non-adhesive
• Temperature resistance: max. 200 degrees C (390 degrees F)
• Thickness: 30 mm
• Fits: Marine engine compartments

🔌 Function

Absorbs airborne engine noise inside the engine space so less of it reaches the accommodation.

⚠️ Common Signs of Failure

• Engine noise noticeably louder in the accommodation than it used to be
• Panel sagging away from the bulkhead
• Facing torn, oil-soaked or crumbling
• Foam compressed flat and no longer springy
• Loose fragments of foam collecting in the bilge

🛠️ Service Notes

• Check you have the depth for 30 mm before ordering - 41103800 is the 20 mm and 41103802 the 50 mm version of the same sheet
• This version has no adhesive backing, so allow for mechanical fixings or insulation hangers
• Cut to shape with a sharp knife, keep the joins tight and cover them with foil tape so noise cannot leak and water cannot get into the foam
• Fit the sheets so the joins are as tight as possible and cover them with foil tape, otherwise noise leaks through and water can be absorbed by the material
• Sound insulation hangers can be used for convenient mounting
• Choose the panel thickness against the engine's own noise characteristics across the 100-8000 Hz range; sound absorption is rated to DIN 52215

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 41103801 → Supersedes 61050213

OEM / Related Numbers

• 61050213 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
