54160-88L00 Suzuki DF60A Lower Mount Assy | Genuine Used Part

54160-88L00 Suzuki DF60A Lower Mount Assy | Genuine Used Part

$100.00 AUD
$100.00 AUD
Sale Sold out
Shipping calculated at checkout.

Low stock: 2 left

🔧 Product Description

Genuine Suzuki DF40A / DF50A / DF60A Lower Rubber Mount - Part Number: 54160-88L00

A genuine Suzuki lower engine mount used in early DF40A, DF50A and DF60A driveshaft-housing assemblies. Two mounts are generally installed to isolate vibration and control side and fore-and-aft movement of the engine within the midsection.

⚙️ Key Features

  • Genuine Suzuki OEM lower mount
  • Correct part number 54160-88L00
  • Two mounts normally required per engine
  • Used on early DF40A-DF60A four-stroke outboards
  • Bonded rubber-and-metal vibration isolator

🚤 Compatibility

  • Suzuki DF40A early model families
  • Suzuki DF50A early model families
  • Suzuki DF60A early model families
  • Documented 2010-2012 DF40A / DF50A / DF60A driveshaft-housing applications
  • Later or configuration-specific engines commonly use 54160-88L10
  • Exact fitment depends on driveshaft-housing and high-thrust configuration

🔌 Function

The lower mounts support the engine within the driveshaft housing, isolate vibration and resist steering and propeller-thrust loads.

⚠️ Common Signs of Failure

  • Rubber separates or hardens
  • Engine moves excessively
  • Clunking occurs during acceleration or reverse
  • Mount bolt corrodes into the sleeve
  • Lower covers show impact marks
  • Steering stability or vibration deteriorates

🔄 Supersession & Cross Reference

OEM Supersession Chain

  • 54160-88L00 is the documented early lower-mount reference
  • 54160-88L10 is a later or alternate mount used on applicable later and high-thrust configurations
  • The L10 version is model- and driveshaft-housing controlled rather than a universal replacement

OEM / Related Numbers

  • 54160-88L00
  • 54160-88L00-000
  • 54160-88L10 later / alternate mount
  • 54151-88L00 / 54151-88L01 lower thrust mount
  • 54166-series lower-mount bolt
  • Related side mounts, dampers and covers

Aftermarket / Verified Equivalents

  • No verified branded aftermarket lower mount
  • Genuine Suzuki 54160-88L00 is the direct replacement for original assemblies
  • Genuine 54160-88L10 is the later OEM alternative only where specified
  • Used genuine mount pairs should be replaced if rubber is compressed or separated

📦 Condition

  • Genuine used part
  • Removed from running engine where applicable
  • In good working condition unless otherwise stated
