67C-81800-02 Aftermarket Mercury Yamaha Starter Motor | Sawley's Select Marine Parts

🔧 Product Description

Aftermarket replacement Yamaha/Mercury F30/F40 Starter Motor - Replaces Part Number: 67C-81800-02

New aftermarket permanent-magnet direct-drive starter replacing Yamaha 67C-81800-02 and the corresponding Mercury/Mariner starter family. It is a 12-volt counter-clockwise starter with a 9-tooth pinion.

⚙️ Key Features

• 12-volt electrical system

• Counter-clockwise rotation viewed from the drive end

• 9-tooth pinion

• Permanent-magnet direct-drive construction

• Yamaha-built four-stroke application shared with Mercury/Mariner

• Complete new starter motor with integrated solenoid

• Marine or engine-grade corrosion-resistant construction

• Direct replacement only after voltage, rotation, tooth count and mounting pattern are confirmed

🧰 Kit / Assembly Contents

• 1 × Complete starter motor assembly - P/N 67C-81800-02

• 1 × Integrated starter solenoid and shift mechanism

• 1 × Installed pinion gear and overrunning clutch/Bendix assembly

• 1 × Installed armature, brush holder, field-magnet/winding and drive housing

• Mounting bolts, battery cables, relays and external wiring are transferred or renewed separately unless supplied

🔄 Supersession & Cross Reference

OEM Supersession Chain:

• 67C-81800-02 → Supersedes/cross-references 67C-81800-00 and 67C-81800-01

OEM / Related Numbers:

• 67C-81800-00

• 67C-81800-01

• 67C-81800-02

• Mercury 50-854636T

• 50-859170T

• 50-884045T

• 50-888160T

• 50-893887T

Aftermarket / Verified Equivalents:

• ARCO: 5365

• API/Protorque: PH130-0028

• Mallory: 9-15018

• Recmar: REC67C-81800-02

🚤 Compatibility

Commonly used on:

• Yamaha-built Yamaha, Mercury and Mariner four-stroke outboard starting systems

Typically suits:

• Engine / Component models:

• Yamaha F30A, principally 2001-2009

• Yamaha F40B, principally 2000-2009

• Mercury/Mariner 30HP and 40HP three-cylinder four-strokes using the listed Mercury cross-reference numbers

• HP Range: 30HP - 40HP

• Year Range: Principally 1999 - 2009

• Component Identification: Corrected classification: Yamaha/Mercury/Mariner outboard starter, not a generic Mercury-only component.

🔌 Function

The starter motor converts battery electrical energy into high-torque mechanical rotation to crank the engine. When the start circuit energises the solenoid, the pinion moves into the flywheel ring gear and the motor turns the crankshaft until combustion begins. The overrunning clutch then protects the starter as engine speed rises.

Common signs of failure / service requirement:

• No-crank condition even though the battery and start-control circuit test correctly

• Solenoid clicks but the starter motor does not rotate

• Starter turns slowly, draws excessive current or overheats the battery cables

• Pinion spins without engaging the flywheel ring gear

• Grinding, clashing or repeated pinion kick-out during cranking

• Intermittent cranking caused by worn brushes, solenoid contacts or heat soak

• Corrosion, water intrusion, burnt windings or excessive shaft/bearing play

📦 Condition

• New aftermarket replacement starter motor

• Brand new

• Supplied in original or equivalent packaging
