688-85542-03-94 Yamaha Coil Bracket | Genuine Used Part

🔧 Product Description

Genuine Yamaha Ignition Electrical Component Bracket - Part Number: 688-85542-03-94

A genuine used Yamaha electrical mounting bracket for selected 75HP, 85HP and 90HP two-stroke outboards. Although commonly described as a coil bracket, Yamaha catalogues identify it simply as a bracket in the electrical-parts assembly, where it supports the CDI, ignition coils, regulator or related electrical components according to model.

⚙️ Key Features

• Genuine Yamaha electrical mounting bracket

• Correct part number 688-85542-03-94

• Used on 75HP to 90HP two-stroke electrical systems

• Supports ignition and control components

• Obsolete original equipment bracket

🔄 Supersession & Cross Reference

OEM Supersession Chain:

• 688-85542-03-94 final verified Yamaha bracket reference

• No confirmed supersession

• Part is discontinued in several catalogues

OEM / Related Numbers:

• 688-85542-03-94

• 688855420394

• 688-85540-series CDI assemblies are related but not included

• 688-85570-series ignition coils are related but vary by model

• Mounting bolts 90101-06M27-00, 90119-06M26-00 and related hardware may appear in the assembly

Aftermarket / Verified Equivalents:

• No aftermarket bracket equivalent

• Used genuine Yamaha brackets are the practical replacement

• Aftermarket CDI units and ignition coils are available separately but do not replace the bracket

🚤 Compatibility

Commonly used on:

• Yamaha 75HP, 85HP and 90HP two-stroke outboards

• Early Yamaha 90A / 90AETO electrical-parts assemblies

• Selected E75 and related Enduro engines

Typically suits:

• Confirmed on 1984-1988 Yamaha 90A / 90ETL electrical diagrams

• Used across selected 75HP-90HP engines into the early 1990s

• Exact mounted components vary by engine year and electrical-system revision

• HP Range: Approximately 75HP - 90HP

• Engine Type: Yamaha three-cylinder two-stroke outboard

• Year Range: Approximately 1984 - early 1990s

• Fitment Requirement: Match bracket holes, CDI / coil layout and regulator position

🔌 Function

The bracket secures ignition and electrical components to the engine so wiring, heat dissipation and vibration isolation remain as designed.

Common signs of failure:

• Cracked bracket

• Corroded mounting surface

• Elongated component holes

• Electrical components vibrating or contacting the cowling

• Broken mounting bolts

📦 Condition

• Genuine used part

• Removed from running engine where applicable

• In good working condition unless otherwise stated
