68F-82170-01-00 68F-82170-01-00 Yamaha Z200 Fuse Box Assy | Genuine Used Part

🔧 Product Description

Genuine Yamaha Fuse Box Assembly - Part Number: 68F-82170-01-00

A genuine Yamaha fuse box assembly used on selected Yamaha Z200 and HPDI two-stroke electrical systems. This assembly houses the main electrical fuses and protects the engine electrical circuits from overload.

⚙️ Key Features

• Genuine Yamaha fuse box assembly

• Correct Yamaha part number 68F-82170-01-00

• Used in Yamaha 68F electrical systems

• Commonly fitted to Z200 HPDI electrical assemblies

• Includes fuse box location for main electrical fuse protection

🔄 Supersession & Cross Reference

OEM Supersession Chain:

• 68F-82170-01-00 Yamaha fuse box assembly reference

OEM / Related Numbers:

• 68F-82170-01-00

• 68F821700100

• 68F-82170-01

• 68F8217001

• Fuse box assembly

• Electrical fuse box

• Yamaha Z200 fuse box

Aftermarket / Verified Equivalents:

• No aftermarket equivalent

🚤 Compatibility

Commonly used on:

• Yamaha 68F HPDI electrical assemblies

Typically suits:

• Engine models:

• Yamaha Z200TXR - 2007 electrical assembly

• Yamaha Z200TXR - 2008 electrical assembly

• Yamaha LZ200TXR electrical assembly

• Yamaha VZ200TLR - 2004 electrical assembly

• Yamaha VZ200TLRC - 2004 electrical assembly

• Yamaha Z200 HPDI 68F electrical systems

• Yamaha LZ200 HPDI 68F electrical systems

• Yamaha VZ200 HPDI 68F electrical systems

• HP Range: commonly 200HP HPDI applications

• Engine Type: Yamaha HPDI two-stroke outboard electrical system

• Year Range: approximately 2004 - 2008 for confirmed Z200 / VZ200 references

• Serial Note: Match by Yamaha model code, electrical assembly diagram and fuse box connector / mounting layout.

🔌 Function

The fuse box assembly houses and protects main fuses for the engine electrical system, helping prevent damage from overload or short circuits.

Common signs of failure:

• Fuse box cracked or damaged

• Fuse terminals corroded

• Fuses not seating securely

• Intermittent electrical power

• Melted fuse holder area

• Engine electrical circuit loses power

• Wiring fault changes when fuse box is moved

📦 Condition

• Genuine used part

• Removed from running engine where applicable

• In good working condition unless otherwise stated
