• 68F-85142-00-94 Yamaha Z200 Reflector Bracket | Genuine Used Part
  • 68F-85142-00-94 Yamaha Z200 Reflector Bracket | Genuine Used Part - photo 2 of 4
  • 68F-85142-00-94 Yamaha Z200 Reflector Bracket | Genuine Used Part - photo 3 of 4
  • 68F-85142-00-94 Yamaha Z200 Reflector Bracket | Genuine Used Part - photo 4 of 4
1 4

68F-85142-00-94 Yamaha Z200 Reflector Bracket | Genuine Used Part

68F-85142-00-94 Yamaha Z200 Reflector Bracket | Genuine Used Part

🔥 50% off all Used Parts - Limited Time 🔥

$40.00 AUD
$80.00 AUD $40.00 AUD
Sale Sold out
Shipping calculated at checkout.

Low stock: 1 left

✓ Authorised Volvo Penta Dealer · Genuine used marine parts · Ships Australia-wide

🔧 Product Description

Genuine Yamaha HPDI Injector-Driver Reflector Bracket - Part Number: 68F-85142-00-94

A genuine used Yamaha bracket identified in the factory catalogue as the reflector bracket for selected 150HP, 175HP and 200HP HPDI V6 outboards.

The bracket forms part of the Electrical 1 assembly and supports or shields components around the injector-driver and engine-control electronics. Yamaha diagrams position it with spacers, collars, electrical covers, the injector-driver assembly and associated mounting hardware.

⚙️ Key Features

  • Genuine Yamaha reflector bracket
  • Correct Yamaha reference 68F-85142-00-94
  • Used within the HPDI electrical and injector-driver assembly
  • Supports electrical shielding and component mounting
  • Factory Yamaha grey-finish code 94

🚤 Compatibility

Commonly used on

  • Yamaha 2.6L HPDI Electrical 1 assemblies
  • Injector-driver and ECU mounting systems
  • Z-series and LZ-series V6 outboards

Typically suits

  • Yamaha Z150
  • Yamaha LZ150
  • Yamaha VZ150
  • Yamaha Z175
  • Yamaha VZ175
  • Yamaha Z200
  • Yamaha LZ200
  • Yamaha VZ200
  • Engines whose electrical diagram specifies 68F-85142-00-94
  • HP Range: 150HP - 200HP
  • Engine Type: 2.6L V6 HPDI two-stroke outboard
  • Year Range: Approximately 2000-2003

🔌 Function

The bracket supports the injector-driver electrical assembly and helps maintain the required separation, mounting and shielding of sensitive electronic components.

⚠️ Common Signs of Failure

  • Injector-driver or electrical cover is loose
  • Bracket is bent
  • Mounting collars or spacers are missing
  • Electrical components vibrate
  • Wiring rubs against the engine
  • Corrosion damages the bracket
  • Mounting holes are cracked
  • Component covers no longer align correctly

🔄 Supersession & Cross Reference

OEM Supersession Chain

  • 68F-85142-00-94 documented Yamaha reflector-bracket reference
  • No verified supersession

OEM / Related Numbers

  • 68F-85142-00-94
  • 68F851420094
  • Spacer: 68F-85516-01-00
  • Collars: 68F-86129-00-00 and 68F-86129-10-00
  • Mounting bolt: 68F-85119-00-00
  • Electrical cover: 68F-85599-00-00
  • Electrical plate: 68F-85644-00-00
  • Injector-driver assembly: 68F-8591B-00-00
  • Earth lead: 6G0-82519-00-00

Aftermarket / Verified Equivalents

  • No aftermarket equivalent

📦 Condition

  • Genuine used part
  • Removed from running engine where applicable
  • In good working condition unless otherwise stated
