🔧 Product Description

Genuine Yamaha Complete Water Pump Repair Kit - Part Number: 692-W0078-02

A genuine Yamaha water-pump repair kit for selected 60HP to 90HP two-stroke outboards.

The kit contains the impeller, water-pump housing and principal gaskets, plates and hardware required to restore cooling-water circulation through the lower-unit pump assembly.

⚙️ Key Features

  • Genuine Yamaha OEM water-pump repair kit
  • Correct Yamaha part number 692-W0078-02
  • Complete pump-service kit with housing and impeller
  • Used on Yamaha 60HP to 90HP two-stroke outboards
  • Cross-references with Sierra complete water-pump kits

🚤 Compatibility

Commonly used on

  • Yamaha 60HP to 90HP two-stroke lower-unit water pumps
  • Conventional and commercial-series gearcases using the 692-series pump housing

Typically suits

  • Engine models:
  • Yamaha 60TLR
  • Yamaha 60TLRC - 2004
  • Yamaha 60TLRD - 2005
  • Yamaha 70TLR
  • Yamaha C75TLR
  • Yamaha P75TLH
  • Yamaha C80
  • Yamaha C85
  • Yamaha CV85
  • Yamaha C90
  • Yamaha 90TLR
  • Yamaha 90TJR
  • Yamaha 90ETL
  • Yamaha 90ETX
  • Yamaha two-stroke 75HP - approximately 1995-1999
  • Yamaha two-stroke 85HP - approximately 1989-1996
  • Yamaha two-stroke 90HP applications using the 692-series pump
  • HP Range: 60HP - 90HP
  • Engine Type: Yamaha carburetted two-stroke outboard
  • Year Range: Approximately mid-1980s through the 2000s, dependent on model

🔌 Function

The water pump draws water through the lower-unit intake and circulates it through the engine's cooling passages.

⚠️ Common Signs of Failure

  • Weak or absent tell-tale flow
  • Engine overheats at idle or under load
  • Impeller blades are cracked or permanently bent
  • Water-pump housing is scored or distorted
  • Pump performance remains poor after replacing only the impeller

🔄 Supersession & Cross Reference

OEM Supersession Chain

  • 692-W0078-02 → Service replacement for 692-W0078-01
  • 692-W0078-01 → Service replacement for 692-W0078-00
  • 692-W0078-00 → Related to 692-W0078-A0

OEM / Related Numbers

  • 692-W0078-02
  • 692-W0078-02-00
  • 692-W0078-01
  • 692-W0078-00
  • 692-W0078-A0
  • 688-44311-01 related water-pump housing

Aftermarket / Verified Equivalents

  • Sierra: 18-3370
  • Sierra: 18-3371
  • Kipa: 692-W0078-02 water-pump kit
  • WINGOGO: 692-W0078-02 replacement kit
  • Oversee Marine: 692-W0078-02 complete kit

📦 Condition

  • Genuine Yamaha part
  • Brand new
  • Supplied in original or equivalent packaging
