6H1-43880-00 Aftermarket Yamaha Trim Motor | Sawley's Select Marine Parts

🔧 Product Description

Aftermarket replacement Complete Power Trim & Tilt Assembly - Replaces Part Number: 69J-43800-0A-8D

New aftermarket complete Yamaha power trim and tilt assembly replacing 69J-43800-0A-8D. It services the large four-stroke and HPDI hydraulic-unit family.

⚙️ Key Features

• Complete electric-hydraulic three-ram trim unit

• Includes motor, pump, valve body and hydraulic rams

• Later service version of the 69J complete assembly

• Supports F200-F300 and selected Z/LZ HPDI engines

• Direct replacement only after bracket and serial confirmation

🧰 Kit / Assembly Contents

• 1 × Complete power trim and tilt assembly - P/N 69J-43800-0A-8D

• 1 × Integrated trim motor

• 1 × Integrated hydraulic pump and valve body

• 1 × Main tilt ram and two trim rams

• External mounting pins and wiring are transferred unless included

🔄 Supersession & Cross Reference

OEM Supersession Chain:

• 69J-43800-0A-8D → Supersedes/cross-references 69J-43800-00/01/02/03/04/05/06/07/08 variants

OEM / Related Numbers:

• 69J-43800-00-8D

• 69J-43800-01-8D

• 69J-43800-02-8D

• 69J-43800-03-8D

• 69J-43800-04-8D

• 69J-43800-05-8D

• 69J-43800-06-8D

• 69J-43800-07-8D

• 69J-43800-08-8D

Aftermarket / Verified Equivalents:

• Aftermarket Yamaha 69J complete trim unit

• Recmar-compatible 69J-43800-0A-8D assembly

🚤 Compatibility

Commonly used on:

• Yamaha large-outboard power trim and tilt systems

Typically suits:

• Engine / Drive models:

• F200 and LF200

• F225 and LF225

• F250 and LF250

• F300 and LF300 applications using the 69J unit

• Z250/LZ250 and Z300/LZ300 HPDI where specified

• HP / Drive Range: 200HP - 300HP

• System Type: Complete outboard electric-hydraulic power trim and tilt assembly

• Year Range: Approximately 2002-2013; model-serial dependent

• Serial / Component Identification: Confirm bracket width, hydraulic-unit suffix and electrical connector.

🔌 Function

The complete electric-hydraulic power trim and tilt unit uses a reversible motor, pump, valve body and hydraulic ram assembly to raise, lower and hold the outboard at the selected angle.

Common signs of failure / service requirement:

• Outboard will not raise, lower or hold position

• Motor runs but the hydraulic ram does not move

• Hydraulic fluid leaks around the motor, pump, valve body or ram

• Movement is slow, jerky or noisy

• Unit drifts down under engine weight

📦 Condition

• New aftermarket replacement part

• Brand new

• Supplied in original or equivalent packaging
