874910 Turbo Pressure Gauge | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta turbo pressure instrument, 52 mm, with a black face and a 0-3 bar scale, weighing 0.104 kg and listed for 100 applications across D and VMM series engines. It supersedes part numbers 873206 and 874920. The white-faced version on the same bar scale is 874924, and the white 0-45 psi version is 874933. Note that pressure gauge 874912 is also a black 0-3 bar instrument but is catalogued separately and listed against a different set of engines, so order by part number if both could suit the panel.

🚤 Compatibility

• Engine Family: D, VMM
• HP Range: 110-480 HP

Full model list at the end of this description.

⚙️ Key Features

• Black face, 0-3 bar scale
• 52 mm instrument
• EVC instrument with anti-fogging membrane and full backlighting
• 0.104 kg
• Listed for 100 applications across D and VMM series engines
• Supersedes 873206 and 874920
• 52mm (Volvo assembly listing)
• Gauge diameter: Ø 52 mm
• Gauge family: Level and pressure gauges
• Gauge range: EVC gauge range
• 52 mm instrument diameter
• Plug-and-play serial connection - adding instruments is easy
• Diameter: 52 mm
• Face colour: Black
• Scale: 0-3 bar
• Also supersedes Volvo part numbers 864018 and 873289

🔌 Function

Shows turbocharger boost pressure at the helm from the engine's boost pressure sender.

⚠️ Common Signs of Failure

• Needle dead with the engine making boost
• Reading that does not rise under load
• Needle hard against the top of the scale
• Backlighting out behind a working needle
• Condensation or staining behind the glass

🛠️ Service Notes

• Check the sender and its connection before replacing the instrument — low or missing boost is more often a wastegate, hose or sender fault than a gauge fault
• Order by units and colour: 874924 is white on the bar scale and 874933 is white on the psi scale
• The 52 mm front ring is ordered separately, in black or chrome to suit the panel thickness
• Front ring and mounting items are not supplied with the instrument and are ordered separately: 52 mm black 874709 or chrome 874733, 85 mm black 874708 or chrome 874732, 110 mm black 3847888 or chrome 3885216 for panels up to 12 mm (15 mm at 110 mm); 881611/881613 in 52 mm and 881612/881614 in 85 mm for panels 12-25 mm; X-rings 874843 in 52 mm and 874844 in 85 mm for flush mounting
• The other face colour is 874924

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 874910 → Supersedes 873206

OEM / Related Numbers

• 874920 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D6-330A-F, D6-370A-F, D6-330D-F, D6-370D-F, D6-300A-F, D6-300D-F, D6-300I-F, D6-340I-G, D6-380I-G, D6-440I-G, D6-480I-G, D6-300A-G, D6-340A-G, D6-380A-G, D6-440I-WJ-G, D6-480I-WJ-G, D6-300D-G, D6-340D-G, D6-380D-G, D6-440D-G, D6-480D-G, D6-400A-G, D6-440A-G, D6-300I-G, D6-330I-F, D6-370I-F, D6-435D-F, D6-400A-F, D6-435I-F, D6-480A-G
• Volvo Penta D4-260A-F, D4-260D-F, D4-260I-F, D4-300A-F, D4-300D-F, D4-180I-F, D4-225I-F, D4-300I-F, D4-225A-F, D4-175I-G, D4-230I-G, D4-270I-G, D4-320I-G, D4-300I-G, D4-150A-G, D4-230A-G, D4-270A-G, D4-320A-G, D4-300A-G, D4-145I-G, D4-175 VG
• Volvo Penta D13C2-B MP, D13C1-A MP, D13C2-A MP, D13C3-A MP, D13C4-A MP, D13B-E MH, D13B-E MH (FE), D13B-N MH, D13B-N MH (FE), D13C4-B MP, D13C5-B MP, D13C6-A MP, D13C1-A MH, D13C2-A MH, D13C5-A MP, D13C7-B MP, D13C8-B MP
• Volvo Penta D3-110I-H, D3-140A-H, D3-170A-H, D3-200A-H, D3-220A-H, D3-150I-H, D3-170I-H, D3-200I-H, D3-220I-H, D3-140I-H
• Volvo Penta D8A2-A MP, D8A5-A MH, D8A6-A MH, D8A5-A MG, D8A6-A MG, D8A4-A MP, D8A1-A MP, D8A3-A MP
• Volvo Penta D11C3-A MP, D11C2-A MP, D11C4-A MP, D11B3-A MP, D11B4-A MP, D11B2-A MP, D11B1-A MP
• Volvo Penta D16C1-E MH, D16C1-F MH, D16C2-E MH, D16C2-F MH
• Volvo Penta D9A2L MH, D9A2M MP
• Volvo Penta VMM-A
