874913 Voltmeter | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta battery voltage instrument, 52 mm, 24 V, with a black face, weighing 0.116 kg and listed for 100 applications across D and VMM series engines. It supersedes part number 873200. This is the 24 V instrument — check the system voltage before ordering. The white-faced 24 V version is 874925, so colour is what separates the pair.

🚤 Compatibility

• Engine Family: D, VMM
• HP Range: 110-480 HP

Full model list at the end of this description.

⚙️ Key Features

• 24 V, black face
• 52 mm instrument
• EVC instrument with anti-fogging membrane and full backlighting
• 0.116 kg
• Listed for 100 applications across D and VMM series engines
• Supersedes 873200
• Gauge diameter: Ø 52 mm
• Gauge family: Temp and voltage gauges
• Gauge range: EVC gauge range
• 52 mm instrument diameter
• 24 V system
• Plug-and-play serial connection - adding instruments is easy
• Diameter: 52 mm
• Face colour: Black
• System voltage: 24 V
• Also supersedes Volvo part numbers 863931 and 873287

🔌 Function

Shows system voltage at the helm so the state of charge and the alternator's output can be watched.

⚠️ Common Signs of Failure

• Needle reading nothing with the system live
• Voltage shown that is well away from a meter reading at the battery
• Needle pinned at the top of the scale
• Panel illumination dead behind a working needle
• Reading that does not lift when the engine is running and charging

🛠️ Service Notes

• Check the actual battery voltage with a meter before condemning the instrument — a charging fault reads like a gauge fault
• Confirm the system is 24 V and pick the face colour: 874925 is the white-faced 24 V version, while 881649 and 881658 are the 12 V pair
• The 52 mm front ring is ordered separately
• Front ring and mounting items are not supplied with the instrument and are ordered separately: 52 mm black 874709 or chrome 874733, 85 mm black 874708 or chrome 874732, 110 mm black 3847888 or chrome 3885216 for panels up to 12 mm (15 mm at 110 mm); 881611/881613 in 52 mm and 881612/881614 in 85 mm for panels 12-25 mm; X-rings 874843 in 52 mm and 874844 in 85 mm for flush mounting
• Four versions are listed and face colour and system voltage are all that separate them: 881649 is black, 12 V; 881658 is white, 12 V; 874925 is white, 24 V
• Match the system voltage - a 12 V gauge will not read correctly on a 24 V system

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 874913 → Supersedes 873200

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D6-330A-F, D6-370A-F, D6-330D-F, D6-370D-F, D6-300A-F, D6-300D-F, D6-300I-F, D6-340I-G, D6-380I-G, D6-440I-G, D6-480I-G, D6-300A-G, D6-340A-G, D6-380A-G, D6-440I-WJ-G, D6-480I-WJ-G, D6-300D-G, D6-340D-G, D6-380D-G, D6-440D-G, D6-480D-G, D6-400A-G, D6-440A-G, D6-300I-G, D6-330I-F, D6-370I-F, D6-435D-F, D6-400A-F, D6-435I-F, D6-480A-G
• Volvo Penta D4-260A-F, D4-260D-F, D4-260I-F, D4-300A-F, D4-300D-F, D4-180I-F, D4-225I-F, D4-300I-F, D4-225A-F, D4-175I-G, D4-230I-G, D4-270I-G, D4-320I-G, D4-300I-G, D4-150A-G, D4-230A-G, D4-270A-G, D4-320A-G, D4-300A-G, D4-145I-G, D4-175 VG
• Volvo Penta D13C2-B MP, D13C1-A MP, D13C2-A MP, D13C3-A MP, D13C4-A MP, D13B-E MH, D13B-E MH (FE), D13B-N MH, D13B-N MH (FE), D13C4-B MP, D13C5-B MP, D13C6-A MP, D13C1-A MH, D13C2-A MH, D13C5-A MP, D13C7-B MP, D13C8-B MP
• Volvo Penta D3-110I-H, D3-140A-H, D3-170A-H, D3-200A-H, D3-220A-H, D3-150I-H, D3-170I-H, D3-200I-H, D3-220I-H, D3-140I-H
• Volvo Penta D8A2-A MP, D8A5-A MH, D8A6-A MH, D8A5-A MG, D8A6-A MG, D8A4-A MP, D8A1-A MP, D8A3-A MP
• Volvo Penta D11C3-A MP, D11C2-A MP, D11C4-A MP, D11B3-A MP, D11B4-A MP, D11B2-A MP, D11B1-A MP
• Volvo Penta D16C1-E MH, D16C1-F MH, D16C2-E MH, D16C2-F MH
• Volvo Penta D9A2L MH, D9A2M MP
• Volvo Penta VMM-A
