876185 Air Filter Insert | Genuine Volvo Penta Part

🔧 Product Description

Air filter insert weighing 0.272 kg, listed as the air filter for the MD30, TMD30, TAMD30 and AQAD30, for the MD40, TMD40, TAMD40, AQD40 and AQAD40, for the KAD32 within the 31-series group, and for the KAD and KAMD 42, 43, 44 and 300. It is listed for 29 applications across the TAMD, KAD and KAMD series and supersedes 463505 and 876129.

🚤 Compatibility

• Engine Family: TAMD, KAD, KAMD

Full model list at the end of this description.

⚙️ Key Features

• Scheduled air filter for the 30- and 40-series, the KAD32 and the KAD and KAMD 42, 43, 44 and 300
• 0.272 kg
• Supersedes 463505 and 876129
• 29 applications across the TAMD, KAD and KAMD series
• Genuine Volvo Penta Part, designed and manufactured to ensure original fit, safety and performance
• Role: Air filter
• Fits: MD30, TAMD30, TMD30, AQAD30; MD31, TMD31, TAMD31, AQAD31, KAD32 (KAD32); MD40, TMD40, TAMD40, AQD40, AQAD40; KAD/KAMD 42, 43, 44, 300
• Also supersedes Volvo part number 842680

🔌 Function

Traps airborne dust and salt before it reaches the turbocharger and cylinders, so the induction air is clean at the ports.

⚠️ Common Signs of Failure

• Element visibly dirty, oily or collapsed
• Loss of power and black smoke under load
• Roaring or whistling from the intake as the element blocks
• Dust tracking found downstream of the element
• Seal or sealing face damaged so air bypasses the filter

🛠️ Service Notes

• On the 31-series only the KAD32 takes this element, while the other engines in that group take 858488 or 21646645 according to housing
• Renew rather than tap out and reuse, and check the element seal and the housing seat, because a bypassing filter does more damage than a dirty one
• Always refer to the operator's manual for the recommended maintenance and service intervals for your engine and drive
• Listed against more than one engine or drive family - check the qualifier that applies to your own engine or drive

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 876185 → Supersedes 463505 → Supersedes 863344

OEM / Related Numbers

• 463505 earlier number superseded by this part
• 863344 earlier number superseded by this part

Aftermarket / Verified Equivalents

• Mallory: 9-57701
• Recmar: REC876185
• Sierra: 18-7890

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta KAD42A, KAD42B, KAD42P-A
• Volvo Penta KAD44P, KAD44P-B, KAD44P-C
• Volvo Penta KAMD42A, KAMD42B, KAMD42P-A
• Volvo Penta KAMD43P, KAMD43P-A, KAMD43P-B
• Volvo Penta KAMD44P-B, KAMD44P-C, KAMD44P-A
• Volvo Penta TAMD72A, TAMD72P-A, TAMD72WJ-A
• Volvo Penta KAD43P-B, KAD43P-A
• Volvo Penta TAMD71B, TAMD71A
• Volvo Penta TAMD73P-A, TAMD73WJ-A
• Volvo Penta KAD300-A
• Volvo Penta KAD32P
• Volvo Penta KAMD300-A
• Volvo Penta TAMD61A
• Volvo Penta TAMD62A
