90119-08196 Yamaha Bolt with Washer | Genuine OEM Yamaha Outboard Part

🔧 Product Description

Genuine Yamaha Water Pump Housing Bolt with Washer - Part Number: 90119-08196

A genuine Yamaha flanged bolt and captive washer used to secure selected lower-unit water-pump housings.

The fastener clamps the pump housing evenly against the gearcase and maintains the correct gasket, plate and impeller-chamber compression.

⚙️ Key Features

• Genuine Yamaha OEM bolt with washer
• Correct current Yamaha part number 90119-08196
• Supersedes earlier fastener 90119-08M16
• Used in selected Yamaha water-pump assemblies
• Factory thread, length and washer dimensions

🚤 Compatibility

Commonly used on

• Yamaha lower-unit water-pump housings
• Complete water-pump repair-kit installations

Typically suits

• Engine / kit applications:
• Yamaha 60HP and 70HP water-pump assemblies
• Yamaha 75HP and 90HP lower units
• Yamaha mid-range pump kits specifying 90119-08196
• Yamaha F425 XTO water-pump assemblies
• Yamaha XF425 XTO lower units
• Yamaha XF450 XTO lower-unit pump assemblies
• Pump housings requiring two or four 90119-08196 fasteners according to the parts diagram
• Thread Size: Yamaha M8 water-pump housing application
• Engine Type: Yamaha two-stroke, four-stroke and XTO outboard
• Year Range: Lower-unit and pump-kit controlled.

🔌 Function

The bolt secures the water-pump housing and maintains even pressure across the gasket and impeller chamber.

⚠️ Common Signs of Failure

• Threads are stretched or damaged
• Bolt head is corroded or rounded
• Captive washer is missing
• Pump housing will not clamp evenly
• Fastener is seized in the gearcase

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 90119-08196 → Supersedes 90119-08M16
• 90119-08M16 earlier OEM water-pump fastener reference

OEM / Related Numbers

• 90119-08196
• 90119-08196-00
• 90119-08M16
• Water-pump housing bolt with washer
• M8 pump-housing fastener

Aftermarket / Verified Equivalents

• No aftermarket equivalent

📦 Condition

• Genuine Yamaha part
• Brand new
• Supplied in original or equivalent packaging
