953036 Stud | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta stud, 38 mm long, weighing 0.007 kg and listed for 77 applications across the AD, TAMD, D, TMD, DP and DPX series and drives. It consolidates four earlier numbers — 876293, 876408, 3582722 and 3582724 — so one stud now covers what were four separate items. Its published weight is shared with 953035, 953044 and 953449, which makes the 38 mm length the only reliable way to pick it out.

🚤 Compatibility

• Engine Family: AD, TAMD, D, TMD, DP, DPX, SP, KAD, KAMD, MD
• HP Range: 110-220 HP

Full model list at the end of this description.

⚙️ Key Features

• 38 mm long
• 0.007 kg
• Consolidates 876293, 876408, 3582722 and 3582724
• 77 applications across six engine and drive series
• Identify by length — three other studs here share its weight
• Quantity varies by assembly, most commonly 12
• Also supersedes Volvo part numbers 3581390, 3581392, 3581415, 3803507, 838758, 859429, 859554 and 875470

🔌 Function

Fixes into the casting and gives the clamping nut a fixed thread to run on, keeping the parent-metal thread out of service.

⚠️ Common Signs of Failure

• Stud comes out with the nut
• Corroded or seized exposed thread
• Necked or stretched below the nut
• Snapped at the casting face
• Weeping or loosening at the joint it clamps

🛠️ Service Notes

• Measure the length before ordering — 953238 and 953240 are also short studs at 38 and 40 mm and share the same published mass band
• Clean out the casting thread before the new stud goes in

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 953036 → Supersedes 3582724

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D3-110I-H, D3-140A-H, D3-170A-H, D3-200A-H, D3-220A-H, D3-150I-H, D3-170I-H, D3-200I-H, D3-220I-H, D3-140I-H
• Volvo Penta AD41P-B, AD41B, AD41D, AD41L-A, AD41P-A, AD41, AD41A, AD41BJ
• Volvo Penta TAMD31L-A, TAMD31M-A, TAMD31P, TAMD31P-A, TAMD31S, TAMD31A, TAMD31B, TAMD31D
• Volvo Penta TAMD41B, TAMD41D, TAMD41H-A, TAMD41H-B, TAMD41M-A, TAMD41P-A, TAMD41A
• Volvo Penta AD31, AD31B, AD31D-A, AD31L-A, AD31P-A, AD31XD
• Volvo Penta DP-A, DP-A1, DP-B, DP-B1
• Volvo Penta KAD42A, KAD42B, KAD42P-A
• Volvo Penta KAD44P, KAD44P-B, KAD44P-C
• Volvo Penta KAMD42A, KAMD42B, KAMD42P-A
• Volvo Penta KAMD43P, KAMD43P-A, KAMD43P-B
• Volvo Penta KAMD44P-B, KAMD44P-C, KAMD44P-A
• Volvo Penta D41, D41B
• Volvo Penta KAD43P-B, KAD43P-A
• Volvo Penta 740A, 290A
• Volvo Penta SP-A, SP-A1
• Volvo Penta TAMD42WJ-A, TAMD42B
• Volvo Penta TMD31A, TMD31B
• Volvo Penta TMD41A, TMD41B
• Volvo Penta DPX
• Volvo Penta KAD300-A
• Volvo Penta KAD32P
• Volvo Penta KAMD300-A
• Volvo Penta MD31A
