953045 Stud | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta stud for the ground cable connection, weighing 0.027 kg and listed for 30 applications across the D, TMD, TAMD and MD series. It supersedes 17967. The earth path is the reason this stud matters — 953261 is the other earth stud listed here, for the ground cable to starter connection — and its published mass is shared with 953071 and the 60 mm stud 953492, so order by the position it serves rather than by weight.

🚤 Compatibility

• Engine Family: D, TMD, TAMD, MD
• HP Range: 110-190 HP

Full model list at the end of this description.

⚙️ Key Features

• For the ground cable connection
• 0.027 kg
• Supersedes 17967
• 30 applications across the D, TMD, TAMD and MD series
• 953261 is the ground cable to starter stud
• Quantity varies by assembly, most commonly four

🔌 Function

Provides the threaded post the earth cable terminal is clamped to, carrying the return current from the electrical system back to the engine block.

⚠️ Common Signs of Failure

• Slow or dead cranking with the batteries known good
• Voltage drop measured across the earth connection
• Corrosion or green deposits building up around the terminal
• Heat discolouration or a burnt smell at the joint
• Terminal loose or the stud turning in the casting

🛠️ Service Notes

• Clean the mating faces back to bright metal — an earth joint fails on contact resistance long before it fails mechanically
• Isolate the batteries before disturbing any earth connection
• Protect the finished joint against salt-laden air once it is tight

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 953045 → Supersedes 17967

OEM / Related Numbers

• 17967 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D3-110I-B, D3-110I-C, D3-130I-C, D3-130A-A, D3-160A-A, D3-130A-B, D3-160A-B, D3-130A-C, D3-160A-C, D3-190A-B, D3-190A-C, D3-190I-A, D3-110I-A, D3-130I-A, D3-160I-A, D3-160I-C, D3-190I-B, D3-190I-C, D3-130I-B, D3-160I-B
• Volvo Penta MD2010-C, MD2010-D
• Volvo Penta MD2020-C, MD2020-D
• Volvo Penta MD2030-C, MD2030-D
• Volvo Penta TMD22B, TMD22P-C
• Volvo Penta TAMD22P-B
• Volvo Penta TAMD31S
