954305 Tube | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta 5/16 inch copper pipe and specified for the water separator, weighing 1.279 kg and covering 232 applications across the D, MD, TMD, MB, AQ and TD series. It consolidates three earlier numbers - 16100, 828227 and 943847 - catalogued previously as a copper tube and as tube. It is the pipe itself rather than a fitting: the 5/16 inch union nut for it is 954322 and the 5/16 inch connector is 190962, while the 3/8 inch equivalents are 954323 and 954337.

🚤 Compatibility

• Engine Family: D, MD, TMD, MB, AQ, TD, AD, AQAD, BB, TAMD, MS, B, HS, AQD, KAD, KAMD
• HP Range: 13-190 HP

Full model list at the end of this description.

⚙️ Key Features

• 5/16 inch copper pipe
• For the water separator
• Union nut 954322 and connector 190962 are the matching 5/16 inch fittings
• 1.279 kg
• Consolidates 16100, 828227 and 943847
• 232 applications across six engine series
• L=195mm / L=250mm / L=5000mm (Volvo assembly listing)
• Size: 5/16 inch
• Fits: Fuel line connections for Volvo Penta fuel filters / water separators 877763, 877765, 877766, 877768, 877769, 877770, 877771, 889280 and 889281

🔌 Function

Carries fuel between the water separator and its neighbouring connections in a rigid, fuel-resistant copper run.

⚠️ Common Signs of Failure

• Fuel weeping or a smell of diesel around the separator
• Chafe marks or a bright wear flat where the pipe touches a bracket
• Work-hardened or cracked copper at a bend, usually near a union
• Flare face damaged, scored or over-tightened
• Pipe distorted or sprung so the union will not pull up square

🛠️ Service Notes

• Renew the union nuts and ferrules with the pipe rather than reusing work-hardened ones
• Support the run properly and never pull a pipe into place with the union - a strained pipe cracks at the flare
• Bleed the fuel system and check every disturbed joint for leaks with the engine running and again warm; a diesel leak in an engine space is a fire risk
• Part of the Volvo Penta fuel line fittings group. Volvo Penta supplies its fuel filters and water separators without connectors or union nuts, so the fittings for the pipe size in use are ordered alongside the filter.

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 954305 → Supersedes 16100

OEM / Related Numbers

• 828227 earlier number superseded by this part
• 943847 earlier number superseded by this part
• 16100 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta 2003, 2003R, 2003R SOLAS, 100S, 110S, 120S-B, 740A, 2003TB, 2003TB SOLAS, 230A, 230B, 250A, 250B, 251A, 120SC, 2001AG, 2001B, 2001BG, 2001D, 2003D, 2003T, 2003TR, 2002AG, 2002B, 2002BG, 2002D, 2003B, 2003B SOLAS, 2003 SOLAS, 2001, 2002, 2001R
• Volvo Penta D3-110I-B, D3-110I-C, D3-130I-C, D3-130A-A, D3-160A-A, D3-130A-B, D3-160A-B, D3-130A-C, D3-160A-C, D3-190A-B, D3-190A-C, D3-190I-A, D3-110I-A, D3-130I-A, D3-160I-A, D3-160I-C, D3-190I-B, D3-190I-C, D3-130I-B, D3-160I-B
• Volvo Penta D2-40, D2-40B, D2-40F, D2-55, D2-55B, D2-55C, D2-55D, D2-55E, D2-55F, D2-50F, D2-75, D2-75B, D2-75C, D2-75F, D2-60F
• Volvo Penta D1-30, D1-30B, D1-30F, D1-13, D1-13B, D1-13F, D1-20, D1-20B, D1-20F
• Volvo Penta AD41P-B, AD41B, AD41D, AD41, AD41A, AD41BJ
• Volvo Penta AD31, AD31B, AD31D, AD31D-A, AD31XD
• Volvo Penta AQ130C, AQ130D, AQ130A, AQ130B
• Volvo Penta AQ131A, AQ131B, AQ131C, AQ131D
• Volvo Penta MD2010, MD2010B, MD2010-C, MD2010-D
• Volvo Penta MD2020, MD2020B, MD2020-C, MD2020-D
• Volvo Penta MD2030, MD2030B, MD2030-C, MD2030-D
• Volvo Penta MD2040, MD2040B, MD2040-C, MD2040-D
• Volvo Penta TAMD31M, TAMD31A, TAMD31B, TAMD31D
• Volvo Penta TAMD41B, TAMD41D, TAMD41M-A, TAMD41A
• Volvo Penta AQ151A, AQ151B, AQ151C
• Volvo Penta AQ170B, AQ170C, AQ170A
• Volvo Penta BB115A, BB115B, BB115C
• Volvo Penta BB170B, BB170C, BB170A
• Volvo Penta D100A, D100BRC, D100B
• Volvo Penta D41, D41B, D41D
• Volvo Penta KAD42A, KAD42B, KAD42P-A
• Volvo Penta KAMD42A, KAMD42B, KAMD42P-A
• Volvo Penta MB20A, MB20B, MB20C
• Volvo Penta MD100A, MD100B, MD100B-CC
• Volvo Penta MD22A, MD22L, MD22P
• Volvo Penta MD5A, MD5B, MD5C
• Volvo Penta MS2B-A, MS2B, MS2V
• Volvo Penta TD100ARC, TD100A, TD100CRC
• Volvo Penta TMD22A, TMD22B, TMD22P-C
• Volvo Penta TMD31A, TMD31B, TMD31D
• Volvo Penta TMD40A, TMD40B, TMD40C
• Volvo Penta TMD41A, TMD41B, TMD41D
• Volvo Penta AQ115A, AQ115B
• Volvo Penta AQ125B, AQ125A
• Volvo Penta AQ145B, AQ145A
• Volvo Penta AQ171A, AQ171C
• Volvo Penta AQAD40B, AQAD40A
• Volvo Penta D70CRC, D70B
• Volvo Penta MD11C, MD11D
• Volvo Penta MD17C, MD17D
• Volvo Penta MD21B, MD21A
• Volvo Penta MD6A, MD6B
• Volvo Penta MD7B, MD7A
• Volvo Penta TAMD40A, TAMD40B
• Volvo Penta TD70CRC, TD70B
• Volvo Penta AD30A
• Volvo Penta AD40B
• Volvo Penta AQ120B
• Volvo Penta AQ140A
• Volvo Penta AQ165A
• Volvo Penta AQAD30A
• Volvo Penta AQD2B
• Volvo Penta AQD21A
• Volvo Penta AQD40A
• Volvo Penta B20
• Volvo Penta BB140A
• Volvo Penta BB145A
• Volvo Penta BB165A
• Volvo Penta BB740A
• Volvo Penta D2002AG
• Volvo Penta D2003AG
• Volvo Penta D42A
• Volvo Penta HS1A
• Volvo Penta MB10A
• Volvo Penta MD1B
• Volvo Penta MD2B
• Volvo Penta MD3B
• Volvo Penta MD30A
• Volvo Penta MD31A
• Volvo Penta MD40A
• Volvo Penta MD67C
• Volvo Penta MS5B
• Volvo Penta TAMD22P-B
• Volvo Penta TAMD30A
• Volvo Penta TAMD42B
• Volvo Penta TMD100A
• Volvo Penta TMD102A
• Volvo Penta TMD30A
