961671 Hose Clamp | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta stainless steel hose clip, weighing 0.029 kg and listed for 111 applications including DPH, D, TSK, IPS, DPI and DPR units, and for engines with keel cooling. Volvo Penta's exhaust system table names it as the recommended stainless steel hose clip for the 45 mm bore wet exhaust hose 1140665, listed in this same run. It consolidates 3589120, 3836316, 40005584, 835697 and 856319, catalogued earlier as a hose clamp and a bracket. Clip 961672 also replaces 3836316, so that old number now maps to two current clips.

🚤 Compatibility

• Engine Family: DPH, D, TSK, IPS, DPI, DPR
• HP Range: 13-480 HP

Full model list at the end of this description.

⚙️ Key Features

• The recommended stainless steel hose clip for wet exhaust hose 1140665, 45 mm bore and 55 mm outside diameter
• For engines with keel cooling
• 0.029 kg
• 111 listed applications
• 3836316 is also replaced by clip 961672
• 55mm (Volvo assembly listing)
• Quantity varies by assembly, most commonly one
• Fits: Rubber exhaust hose 1140665 (45 mm internal diameter)

🔌 Function

Draws a stainless band tight around an exhaust hose end so the hose seals against the spigot beneath it.

⚠️ Common Signs of Failure

• Exhaust gas or water leaking at the hose joint
• Sooty or salt-crusted staining round the clip
• Band corroded and the screw seized
• Stripped screw thread so the clip cannot be pulled up
• Band cutting into the hose wall

🛠️ Service Notes

• An exhaust hose joint that leaks is putting gas and water into the boat - renew the hose and both clips rather than just re-tightening
• Where an engine is documented against 3836316, compare this clip with 961672 before ordering, as that number now covers both

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 961671 → Supersedes 3589120 → Supersedes 3836316 → Supersedes 40005584 → Supersedes 835697 → Supersedes 856319 → Supersedes 3587411 → Supersedes 3587413

OEM / Related Numbers

• 835697 earlier number superseded by this part
• 856319 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D6-370A-C, D6-350A-A, D6-350A-B, D6-330A-D, D6-330A-F, D6-370A-F, D6-330A-C, D6-370A-D, D6-330A-E, D6-370A-E, D6-280I-D, D6-310I-D, D6-300A-F, D6-330I-C, D6-330I-D, D6-310A-B, D6-280A-C, D6-310A-C, D6-310A-A, D6-280A-D, D6-310A-D, D6-280A-E, D6-310A-E, D6-280I-C, D6-310I-C, D6-280A-A, D6-280A-B, D6-340I-G, D6-380I-G, D6-440I-G, D6-480I-G, D6-300A-G, D6-340A-G, D6-380A-G, D6-440I-WJ-G, D6-480I-WJ-G, D6-300D-G, D6-340D-G, D6-380D-G, D6-440D-G, D6-480D-G, D6-400A-G, D6-440A-G, D6-300I-G, D6-400A-E, D6-400A-F, D6-330A-B, D6-370A-B, D6-480A-G
• Volvo Penta D4-260A-B, D4-260A-A, D4-260A-C, D4-260A-D, D4-260A-E, D4-260A-F, D4-300A-A, D4-300A-C, D4-300A-D, D4-300A-E, D4-300A-F, D4-225I-C, D4-225I-D, D4-210A-A, D4-210A-B, D4-225A-B, D4-225A-C, D4-225A-D, D4-225A-E, D4-225A-F, D4-175I-G, D4-230I-G, D4-270I-G, D4-320I-G, D4-300I-G, D4-150A-G, D4-230A-G, D4-270A-G, D4-320A-G, D4-300A-G, D4-145I-G
• Volvo Penta D1-30, D1-30B, D1-30F, D1-13, D1-13B, D1-13F, D1-20, D1-20B, D1-20F
• Volvo Penta D8A5-A MH, D8A6-A MH, D8A5-A MG, D8A6-A MG, D8A1-A MP, D8A3-A MP
• Volvo Penta DPH-D1, DPH-E, DPH-A, DPH-C
• Volvo Penta DPR-A, DPR-C, DPR-D, DPR-B
• Volvo Penta D2-40, D2-40B, D2-40F
• Volvo Penta IPS10-A, IPS10-B
• Volvo Penta TSK DPH-A, TSK DPH-B
• Volvo Penta DPI-A
