991005 Shim | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta shim 0.10 mm thick, listed for 30 applications across the D and IPS ranges. It is one of four shims in this run, which run 0.10 mm, 0.15 mm and 0.35 mm.

🚤 Compatibility

• Engine Family: D, IPS

Full model list at the end of this description.

⚙️ Key Features

• 0.10 mm thick
• 30 applications across the D and IPS ranges
• One of a graded set of shims

🔌 Function

Takes up clearance in an assembly, the stack of shims setting the end float or preload to the figure the build calls for.

⚠️ Common Signs of Failure

• End float or preload out of specification on measurement
• Knock or rumble from an assembly that has gone slack
• Shim dished, torn or picked up at the edge
• Shim face fretted where it has been working

🛠️ Service Notes

• Order by the stamped or measured thickness - the published weights do not separate this set and must not be used to choose between the shims
• Shim 991008 is also listed at 0.10 mm but for 19 applications rather than 30, so thickness alone does not separate those two - order by part number against the application
• Measure the existing stack before stripping and set the new stack to the figure in the manual

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D13C2-B MP, D13C2-A MP, D13C4-A MP, D13B-L MP, D13B-G MP, D13B-K MP, D13B-C MP, D13C6-A MP, D13C4-B MP, D13C5-B MP, D13C5-A MP, D13C7-B MP, D13C8-B MP
• Volvo Penta D11C2-A MP, D11C4-A MP, D11B4-A MP, D11B2-A MP, D11A-C MP, D11A-D MP, D11A-E MP
• Volvo Penta IPS2-C, IPS2-A, IPS2-B
• Volvo Penta IPS20-D, IPS20-E
• Volvo Penta IPS3-C, IPS3-A
• Volvo Penta IPS30-E, IPS30-D
• Volvo Penta D8A4-A MP
