BUHXW-1 NGK Standard Spark Plug | Genuine NGK Spark Plug

🔧 Product Description

NGK Standard Spark Plug – Part Number: BUHXW-1

Spark plugs are a critical engine component, providing the spark that ignites the air-fuel mixture that drives an engine. NGK spark plugs feature trivalent plating – a silver/chrome-coloured finish on the threads – for corrosion resistance against moisture and chemicals, and are designed to meet or exceed OE standards.

⚙️ Key Features

• Standard nickel centre electrode
• Trivalent metal plating provides superior anti-corrosion and anti-seizing properties
• Corrugated ribs reduce the risk of flashover
• Pure alumina silicate ceramic insulator, providing superior strength and better heat transfer
• Copper core aids in heat removal
• Triple seals prevent leakage

📏 Specifications

• NGK stock number: 5526
• Thread: 14 mm
• Reach: 12.7 mm (1/2 in)
• Hex: 20.8 mm (13/16 in)
• Seat: Gasket
• Terminal: Solid
• Type: Tungsten Electrode

🚘 Application

Listed in NGK's application charts for marine, motorcycle, ATV and snowmobile equipment. The chart shows a 1.0 mm gap for these engines, but check it against your engine's manual before fitting.

• Omc SEA DRIVE-2.5L (1984-1981) – Inboard Engine
• Omc SEA DRIVE-2.6L 190-SD (1988-1985) – Inboard Engine
• Evinrude (235 HP, 1985-1978) – Outboard Engine
• Evinrude (200 HP, 1983-1976) – Outboard Engine
• Evinrude COM (200 HP, 1992) – Outboard Engine
• Evinrude (175 HP, 1987-1977) – Outboard Engine
• Evinrude COM CV6 (155 HP, 1992-1989) – Outboard Engine
• Evinrude CV6 (155 HP, 1987-1978) – Outboard Engine
• Evinrude CV6 (150 HP, 1987-1978) – Outboard Engine
• Evinrude 140 (140 HP, 1984-1973) – Outboard Engine
• Evinrude (135 HP, 1984-1973) – Outboard Engine
• Evinrude (115 HP, 1985) – Outboard Engine
• Evinrude COM (100 HP, 1998-1984) – Outboard Engine
• Evinrude (65 HP, 2001-1998) – Outboard Engine
• Evinrude COM HC LC (65 HP, 1997-1988) – Outboard Engine
• Evinrude COM (55 HP, 2003-1986) – Outboard Engine
• Evinrude COM (45 HP, 2003-1991) – Outboard Engine
• Evinrude 3-CYL. (40 HP, 2003-1984) – Outboard Engine
• Evinrude COM (25 HP, 1998-1981) – Outboard Engine
• Evinrude COMMERCIAL (25 HP, 2001-1999) – Outboard Engine
• Evinrude KERO (15 HP, 1998-1995) – Outboard Engine
• Johnson LV6 (250 HP, 2001-1999) – Outboard Engine
• Johnson (235 HP, 1985-1978) – Outboard Engine
• Johnson (175 HP, 1987-1977) – Outboard Engine
• Johnson CV6 (150 HP, 1987-1978) – Outboard Engine

That is the 25 most common of 35 applications NGK's charts list for this plug – ask us to check yours.

🔄 Supersession & Cross Reference

NGK's cross-reference tables list this plug against these part numbers.

• Champion: 831, 831M, 831S, 876-1, 876M, 876S, QL16V, QL16V S and 2 more
• ACDelco: VB40FFM
• DENSO: SF10

📦 Condition

• Brand new genuine product
• Supplied in original packaging
