CMR5H NGK Standard Compact Spark Plug | Genuine NGK Spark Plug

CMR5H NGK Standard Compact Spark Plug | Genuine NGK Spark Plug

$15.00 AUD
$15.00 AUD
Sale Sold out
Shipping calculated at checkout.

✓ Authorised Volvo Penta Dealer · Marine & auto specialists · Ships Australia-wide

🔧 Product Description

NGK Standard Compact Spark Plug – Part Number: CMR5H

Spark plugs are a critical engine component, providing the spark that ignites the air-fuel mixture that drives an engine. NGK spark plugs feature trivalent plating – a silver/chrome-coloured finish on the threads – for corrosion resistance against moisture and chemicals, and are designed to meet or exceed OE standards.

⚙️ Key Features

  • Standard nickel centre electrode
  • Trivalent metal plating provides superior anti-corrosion and anti-seizing properties
  • Corrugated ribs reduce the risk of flashover
  • Pure alumina silicate ceramic insulator, providing superior strength and better heat transfer
  • Copper core aids in heat removal
  • Triple seals prevent leakage

📏 Specifications

  • NGK stock number: 7599
  • Thread: 10 mm
  • Reach: 12.7 mm (1/2 in)
  • Hex: 16 mm (5/8 in)
  • Seat: Gasket
  • Terminal: Solid
  • Type: Compact

🚘 Application

Listed in NGK's application charts for lawn, garden and commercial equipment. The chart shows a 0.5 mm gap for these engines, but check it against your engine's manual before fitting.

  • Transfer Pump 100166 (31cc) – Outdoor Power Equipment
  • Tiller FG110 (1.1HP GX25) – Outdoor Power Equipment
  • Trimmer/Brushcutter HTT25, HHT25S (1.1HP GX25) – Outdoor Power Equipment
  • Trimmer/Brushcutter HHT25SLTA (HONDA GX25) – Outdoor Power Equipment
  • Trimmer/Brushcutter HHT35S (1.1HP GX25) – Outdoor Power Equipment
  • Trimmer/Brushcutter HHT35SLTA (HONDA GX35) – Outdoor Power Equipment
  • Trimmer/Brushcutter HHT35SUKA (HONDA GX35) – Outdoor Power Equipment
  • Trimmer/Brushcutter UMC425 (HONDA GX25) – Outdoor Power Equipment
  • Trimmer/Brushcutter UMC435 (HONDA GX35) – Outdoor Power Equipment
  • Honda WX10 (HONDA GX25) – Outdoor Power Equipment
  • Honda WX10K (1.1HP GX25) – Outdoor Power Equipment
  • Blower EB254 (24.5cc) – Outdoor Power Equipment
  • Blower EB344 (34cc) – Outdoor Power Equipment
  • Blower EB854, EB854RT (79.7cc) – Outdoor Power Equipment
  • Brush Cutter, Edger C254 (24.5cc) – Outdoor Power Equipment
  • Brush Cutter, Edger C344 (34cc) – Outdoor Power Equipment
  • Brush Cutter, Edger LE254 (24.5cc) – Outdoor Power Equipment
  • Hedge Trimmer AH254, AHS254 (ARTICULATING) (24.5cc) – Outdoor Power Equipment
  • Hedge Trimmer DH254-24, DH254-30 (24.5cc) – Outdoor Power Equipment
  • Hedge Trimmer HT254-30, HT254-40 (24.5cc) – Outdoor Power Equipment
  • Lawn Edger LE254 (24.5cc) – Outdoor Power Equipment
  • Multi Tool M254 (24.5cc) – Outdoor Power Equipment
  • Power Broom PS344 (34cc) – Outdoor Power Equipment
  • Trimmer/Brushcutter C254 (25.5cc) – Outdoor Power Equipment
  • Trimmer/Brushcutter C344 (34cc) – Outdoor Power Equipment

That is the 25 most common of 39 applications NGK's charts list for this plug – ask us to check yours.

🔄 Supersession & Cross Reference

NGK's cross-reference tables list this plug against these part numbers.

  • Bosch: UFR7EC, USR7AC

📦 Condition

  • Brand new genuine product
  • Supplied in original packaging
