🔧 Product Description

Aftermarket major service kit for selected Mercury and Mariner 50HP, 55HP and 60HP inline three-cylinder carburetted two-stroke outboards within serial range 0D000750-0G589999. This package is configured for the standard small-gearcase engine family using the 47-19453T impeller system; it is not the later 821354A2 pump family and is not suitable for BigFoot or large-gearcase models.

The serial span covers two commonly catalogued production groups—0D000750-0G290584 and 0G290585-0G589999—while retaining the same core three-cylinder service configuration. Engine serial number, gearbox type and existing water-pump arrangement must all be checked before ordering.

⚙️ Key Features

• Major annual-service package for early Mercury/Mariner inline-three two-stroke outboards

• Correctly grouped around the standard small-gearcase 47-19453T impeller family

• Includes ignition, fuel, thermostat, gearcase-drain and water-pump service items

• Uses recognised marine aftermarket replacements for the corresponding Mercury references

• Suitable for routine preventive maintenance and cooling-system renewal

📋 Kit Contents

• 3 × NGK BP8H-N-10 spark plugs - Mercury/Quicksilver reference family 33-97182Q / 33-97182B; RFI-suppressed BPZ8H-N-10 may be specified on installations requiring a resistor plug

• 1 × Inline fuel filter - replaces Mercury 35-877565T / 35-877565T1

• 1 × 120°F / approximately 49°C thermostat - Mercury 14586-series reference; earlier engines may catalogue 14586A4 and later engines 14586A6

• 1 × Thermostat gasket - Mercury 27-43006-8

• 1 × Water-pump impeller - Mercury 47-19453T; also catalogued through 47-19453T2 / 47-19453T3 revisions

• 1 × Upper water-pump gasket - Mercury 27-822189

• 1 × Lower water-pump gasket/seal - Mercury 27-19701, later serviced by 8M4502052 in current replacement packages

• 2 × Gearcase drain/fill screw sealing washers - Mercury 12-191833 family

Related complete water-pump repair kit, when the plate, key and tube seal also require renewal:

• 1 × Complete pump repair kit - Mercury/Quicksilver 47-19453Q2 / 19453Q02

• 1 × Impeller - 47-19453T

• 1 × Drive key - 28-8M0032831

• 1 × Wear plate - 19700A2

• 1 × Upper gasket - 27-822189

• 1 × Lower gasket/seal - 27-19701 / 8M4502052

• 1 × Water-tube seal/coupler - 859770 / 8597701 / 893857, with later service replacement 8M0204658 depending pump version

• Associated washers/seals - 12-858234 and/or 8M0005777 according to the current kit revision

🔄 Supersession & Cross Reference

OEM / Related References:

• Mercury/Quicksilver 47-19453T, 47-19453T2, 47-19453T3 - Impeller family

• Mercury/Quicksilver 47-19453Q2 / 19453Q02 - Complete pump repair kit

• Mercury 14586A4 / 14586A6 - Thermostat kit references

• Mercury 35-877565T / 35-877565T1 - Fuel-filter references

Verified Aftermarket / Other-Brand Equivalents:

• Sierra 18-3213 - Complete water-pump repair kit equivalent

• GLM 12224 - Complete water-pump repair kit equivalent

• WSM 725-230 - Complete water-pump repair kit equivalent

• SEI 96-265-03AK - Complete water-pump repair kit equivalent

• HJ-MHJB-19453Q02 - Complete water-pump repair kit equivalent

• Sierra 18-3549 - 120°F thermostat equivalent for the Mercury 14586 family

🚤 Compatibility

Commonly used on selected:

• Mercury 50HP three-cylinder carburetted two-stroke outboards

• Mercury 55HP three-cylinder carburetted two-stroke outboards where catalogued with the same standard gearcase

• Mercury 60HP three-cylinder carburetted two-stroke outboards with standard small gearcase

• Corresponding Mariner-branded versions of the same Mercury-built engine family

Serial Range:

• 0D000750-0G290584

• 0G290585-0G589999

• Combined serial range: 0D000750-0G589999

Typical Production Period:

• Primarily early-to-mid 1990s through approximately 1997, subject to market and model designation

Important Exclusions:

• Not for 60HP BigFoot or large-gearcase models using 47-43026Q06 / 8M0100526 pump components

• Not for later 50HP engines using the 821354A2 water-pump family

• Not for EFI four-stroke engines

• Not for four-cylinder, OptiMax/DFI or Command Thrust models

🔌 Function

Provides the principal ignition, fuel, thermostat, gearcase-sealing and water-pump consumables required for a comprehensive scheduled service. Replacing these items helps maintain reliable starting, correct combustion, fuel flow, cooling-water delivery and gearcase oil sealing.

Common signs service is due include:

• Difficult starting, misfire or fouled spark plugs

• Restricted fuel flow or deteriorated fuel-filter media

• Engine running too cold, overheating or unstable operating temperature

• Weak tell-tale flow, elevated cylinder-head temperature or damaged impeller vanes

• Milky gear oil or seepage around drain/fill screws caused by reused sealing washers

📦 Condition

• Brand-new aftermarket service kit

• Supplied with new, unused service components

• Individual component brands may vary according to current supply, while matching the listed OEM references

• Confirm engine serial number, standard gearbox and existing pump design before installation
