8M0120867 Aftermarket Mercury 9.9HP Carb (209cc) (0P325500-1R279944) Command Thrust Service Kit | Sawley's Select Marine Parts

🔧 Product Description

Aftermarket Mercury 9.9HP Carburetted 209cc Command Thrust Service Kit - Kit Reference: 8M0120867

A major service package for Mercury 9.9HP carburetted 209cc Command Thrust outboards. The Command Thrust gearcase uses the separately listed impeller, wear plate and gasket components and must not be confused with standard kit 8M0120837.

⚙️ Key Features

• Application-specific major service package

• Exact serial-range separation prevents mixing incompatible fuel filters, thermostats or gearcase pump parts

• Includes engine and gearcase drain-plug sealing components where applicable

• Includes the correct spark-plug type and quantity for the listed engine family

• Water-pump components match the stated standard, BigFoot or Command Thrust gearcase

🔄 Supersession & Cross Reference

OEM Supersession Chain:

• 8M0120867 (aftermarket/OEM-channel application reference)

• 8M0135803 → Current Command Thrust impeller reference

OEM / Related Numbers:

• 8M0120867

• 35-16248

• 895146

• 8M0075255

• 8M0119207

• 8M0204682

• 27-8M0075040

• 803753

• 8M0135803

Aftermarket / Verified Equivalents:

• Sawley's Select aftermarket-equivalent component package

Included Components:

• 1 × Fuel filter - 35-16248

• 1 × Engine-oil drain gasket - 895146

• 2 × Gearcase drain seals - 8M0075255

• 1 × Thermostat - 8M0119207

• 2 × NGK DCPR6E / 8M0204682 spark plugs

• 1 × Water-pump gasket - 27-8M0075040

• 1 × Wear plate - 803753

• 1 × Impeller - 8M0135803

🚤 Compatibility

Commonly used on:

• Mercury 9.9HP Carburetted 209cc Command Thrust outboard service applications

Typically suits:

• Engine models:

• Mercury 9.9HP FourStroke carburetted 209cc Command Thrust

• Mercury 9.9HP ProKicker carburetted Command Thrust variants in the stated range

• HP Range: 9.9HP

• Engine Type: 209cc carburetted inline-two four-stroke with Command Thrust gearcase

• Year Range: Serial-specific production group

• Serial Range: 0P325500-1R279944

🔌 Function

The service kit groups the routine ignition, lubrication, fuel-system, cooling-system and gearcase consumables required for a major scheduled service. Replacing the listed components helps maintain reliable starting, correct operating temperature, clean fuel delivery, adequate cooling-water flow and secure engine and gearcase sealing.

Common signs service is due:

• Hard starting, rough idle or misfire from worn or fouled spark plugs

• Restricted fuel delivery or unstable engine speed from a contaminated filter

• Engine temperature runs high because the thermostat or water pump is deteriorated

• Low oil pressure, dirty engine oil or a restricted oil filter on four-stroke engines

• Water or lubricant leakage from reused drain-plug seals

• Reduced cooling-water discharge or damaged impeller vanes

📦 Condition

• Brand new aftermarket service kit

• New and unused components

• Supplied in manufacturer or equivalent protective packaging
