QDE-CENTERS Quad EVO Centre Pair LED Driving Lights Bundle | Genuine STEDI Product

🔧 Product Description

Quad EVO Centre Pair LED Driving Lights Bundle - Part Number: QDE-CENTERS

Introducing QUAD EVO LED Driving Lights. STEDI has taken one of its legacy driving lights, the QUAD PRO, and incorporated innovative enhancements. This elegantly designed driving light elevates beyond the QUAD PRO while infusing it with the quintessential EVO DNA, resulting in a more organically shaped driving light that delivers superior performance. Designed as a modular system, QUAD EVO features a Centre Light and Side Light, utilising a combination of spot + flood reflectors for optimal optical performance, which collectively provides an impressive 210-degree distribution of pure light. This bundle is a pair of QUAD EVO Centre Lights.

The QUAD EVO ‘central light’ is equipped with 23 CREE XP20 LEDs, utilising a combination of spot + flood reflectors for optimal optical performance. Additionally, QUAD EVO is also available as a ‘side light’ consisting of 18 CREE XP20 LEDs, enhanced by 5x widespread reflectors (also known as side-shooters). For optimal reach and distribution, employing 2x QUAD EVO centre lights with 2x QUAD EVO side lights achieves a remarkable range of up to 1015 metres at 1 lux (effective), delivering an exceptional 210-degree illumination spread.

The QUAD EVO’s aesthetic adaptation features a sleek, organic silhouette that reflects the contemporary grille designs of today. Both the QUAD EVO Centre Light and Side Light embody the EVO aesthetics, characterised by low profile mounting brackets, minimal exposed hardware, and an engaging visual depth created by lenses, fascia and covers, with STEDI's innovative snap-fit covers. While the overall depth has increased compared to its predecessor, the light unit is positioned further forward, facilitating easier installation on modern bull bars, so the overall footprint is comparable to the QUAD PRO.

In accordance with the EVO series, the QUAD EVO renders a 5000 Kelvin colour temperature, which minimises glare on road signs while promoting a soft and consistent lighting output to reduce eye fatigue. Both QUAD EVO centre and side lights are IP68 rated for water, dust and mud resilience (submersible up to 3m), offer a lifespan of up to 30,000* hours at operational temperatures of -40℃ to 60℃, and are engineered with an Aluminium ADC12 housing with modern fins for maximum heat dissipation. The reconfigured bracket system provides a variety of mounting solutions, perfect for modern bull bars with minimal mounting clearances, roof rack arrays and smaller off-road vehicles like ATVs.

Each QUAD EVO Centre Light comes out of the box with 1x STEDI Black Out Cover, 1x Colour Fascia Grey and 1x Colour Fascia Orange, plus the STEDI custom key that effortlessly removes each colour fascia (and doubles as a bottle opener), all required mounting hardware, stainless steel mounting bracket and a STEDI branded patch. If you want to match QUAD EVO with any other Type-X EVO driving light or light bar, the covers and fascia will all match.

Kit includes

• ST-01-QDE-002 Quad EVO LED Driving Light (Centre Module) x2

Optional extras (sold separately)

• WIRQKFT-SMART Dual Connector Plug & Play SMART Harness High Beam Driving Light Wiring - $69.00 RRP
• ST-31-DTP-004 4x Connector (Quad) Plug & Play SMART Harness High Beam Driving Light Wiring - $119.00 RRP
• ST-12-QDE-001 Quad EVO Anti Theft Kit - $40.00 RRP
• Quad EVO Centre Covers - Smiley, Carbon Fibre, Amber, STEDI, STEDI Owl or Clear (ST-12-QDE-921 to 926) - $25.00 RRP each
• Quad EVO Centre Colour Fascia Rings - Graphite, Red, Blue, Green, Pink, Carbon, Orange or White (ST-12-QDE-821 to 828) - $20.00 RRP each

📦 Condition

• Brand new genuine product
• Supplied in original packaging
